This product is out of stock
We can email you when it's back in stock, confirm expected lead times, or recommend in-stock alternatives that meet the same requirements.
StarTech.com 20m (65ft) LC to SC (UPC) OS2 Single Mode Duplex Fiber Optic Cable, 9/125�m, Laser Optimized, 10G, Bend Insensitive, Low Insertion Loss - LSZH Fiber Patch Cord (SMLCSC-OS2-20M) - Patch cable - LC/UPC single-mode (M) to SC/UPC single-mode (M) - 20 m - 2 mm - fibre optic - duplex - 9 / 125 micron - OS1/OS2 - halogen-free, passive - yellow
- OS2
- 20 m
- LC Male
- SC Male
- Connector polish type: PC
- Jacket material: Low smoke zero halogen (LSZH), Polypropylene
- 10 Gbit/s
- Full duplex Single-mode
- Yellow
Similar Products
Overview
StarTech.com 20m (65.6ft) LC to SC (UPC) OS2 Single Mode Duplex Fiber Optic Cable, 9/125µm, 100G, Bend Insensitive, Low Insertion Loss - LSZH Fiber Jumper Cord
Specifications
Features
- Cable length
- 20 m
- Connector 1
- LC
- Connector 2
- SC
- Connector 1 gender
- Male
- Connector 2 gender
- Male
- Product colour
- Yellow
- Jacket material
- Low smoke zero halogen (LSZH), Polypropylene
- Fibre optic type
- OS2
- Connector polish type
- PC
- Full duplex
- Yes
- Core diameter
- 9 µm
- Cladding diameter
- 125 µm
- Fiber mode structure
- Single-mode
- Wavelengths supported
- 1260,1280,1300,1310,1383,1490,1550,1590,1600,1625 nm
- Data transfer rate
- 10 Gbit/s
- Insertion loss
- 0.3 dB
- Return loss
- 55 dB
Certificates
- Compliance certificates
- RoHS
Operational conditions
- Operating temperature (T-T)
- -20 - 60 °C
- Storage temperature (T-T)
- -20 - 60 °C
Weight & dimensions
- Cable diameter
- 2 mm
- Bending radius
- 1 cm
Packaging data
- Package width
- 200 mm
- Package depth
- 220 mm
- Package height
- 3 mm
- Package weight
- 151.2 g
Packaging content
- Quantity per pack
- 1 pc(s)
Other features
- Attenuation (max)
- 0.35 dB/km
Logistics data
- Master (outer) case width
- 380 mm
- Master (outer) case length
- 380 mm
- Master (outer) case height
- 280 mm
- Products per master (outer) case
- 400 pc(s)
Sustainability
- Sustainability compliance
- Yes
