StarTech.com 4 Port HDMI KVM Switch, Single Monitor 4K 60Hz Ultra HD HDR, Desktop HDMI 2.0 KVM Switch with 2 Port USB 3.0 Hub (5Gbps) & 4x USB 2.0 HID Ports, Audio, Hotkey Switching, TAA - KVM with Fast Switching - KVM / audio switch - 4 x KVM / audio - 1 local user - desktop, rack-mountable - TAA Compliant
- Black
- Number of computers controlled: 1
- Keyboard port type: USB Mouse port type: USB Video port type: HDMI
- 4K Ultra HD 3840 x 2160 pixels
- Housing material: Steel
- Hot keys
- 36 W
Similar Products
Overview
StarTech.com 4 Port HDMI KVM Switch - Single Monitor 4K 60Hz Ultra HD HDR - Desktop HDMI 2.0 KVM Switch with 2 Port USB 3.0 Hub (5Gbps) and 4x USB 2.0 HID, Audio - Hotkey Switching - TAA
Specifications
Ports & interfaces
- Number of computers controlled
- 1
- Keyboard port type
- USB
- Mouse port type
- USB
- Video port type
- HDMI
- Console ports
- 3.5mm headphone, 3.5mm mic, HDMI, USB A
- HDMI ports quantity
- 5
- HDMI version
- 2.0
- USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity
- 4
- Console USB ports quantity
- 4
- USB hub
- Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity
- 2
- Audio connections
- Yes
- Headphone outputs
- 5
- Number of microphone inputs
- 5
- DC-in jack
- Yes
Performance
- HD type
- 4K Ultra HD
- Maximum resolution
- 3840 x 2160 pixels
- Data transfer rate (max)
- 5 Gbit/s
- Scan interval
- 3,8,15,30 s
- Daisy chain
- No
- Chipset
- Genesys Logic - GL3523
- Audio channels
- 7.1
Design
- Product colour
- Black
- Housing material
- Steel
- LED indicators
- Yes
- Push button
- Yes
- Hot keys
- Yes
- Mean time between failures (MTBF)
- 143000 h
- Certification
- CE, FCC, RoHS
Display
- Built-in display
- No
- On Screen Display (OSD)
- No
Power
- Input voltage
- 100 - 240 V
- Input current
- 1 A
- Output voltage
- 12 V
- Output current
- 3 A
- Power consumption (typical)
- 36 W
- Power plug type
- Type M
- Compatible power plug types
- EU, UK, US
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -10 - 60 °C
- Operating relative humidity (H-H)
- 0 - 80%
Weight & dimensions
- Width
- 130 mm
- Depth
- 220 mm
- Height
- 44 mm
- Weight
- 1.1 kg
Packaging data
- Package width
- 212 mm
- Package depth
- 409 mm
- Package height
- 87 mm
- Package weight
- 1.8 kg
Packaging content
- Manual
- Yes
- Rubber feet
- Yes
Logistics data
- Harmonized System (HS) code
- 85176200
- Master (outer) case width
- 545 mm
- Master (outer) case length
- 438 mm
- Master (outer) case height
- 258 mm
- Products per master (outer) case
- 6 pc(s)
Other features
- IP control
- No
