This product is out of stock
We can email you when it's back in stock, confirm expected lead times, or recommend in-stock alternatives that meet the same requirements.
StarTech.com HDMI Over IP Extender - 1080p - HDMI Video and USB Over IP Distribution Kit with Video Wall Support - HDMI and USB Over LAN (ST12MHDLANU) - Video/audio/USB extender - up to 100 m - for P/N: ST12MHDLANUR
- AV transmitter & receiver 1920 x 1200 pixels Black
- Maximum transfer distance: 100 m
- 60 Hz
Similar Products
Overview
StarTech.com HDMI and USB over IP Distribution Kit - 1080p
Specifications
Features
- Type
- AV transmitter & receiver
- Maximum resolution
- 1920 x 1200 pixels
- Cable types supported
- Cat5e
- Maximum transfer distance
- 100 m
- Maximum refresh rate
- 60 Hz
- Audio system
- stereo
- LED indicators
- Link, Power, Reset
- Supported video modes
- 720p, 1080p
- Material
- Aluminium
- Rack mounting
- Yes
- Daisy chain
- Yes
- Product colour
- Black
- Certification
- CE, FCC, TAA, REACH
Ports & interfaces
- RJ-45 input ports
- 1
- RJ-45 output ports
- 1
- HDMI in
- 1
- Number of HDMI outputs
- 1
- USB ports quantity
- 5
- USB connector type
- USB Type-A, USB Type-B
Power
- AC input voltage
- 100-240 V
- Operating voltage
- 5 V
- Input current
- 0.6 A
- Output current
- 1.5 A
- External power adapter
- Yes
- Current
- 2 A
- Power plug type
- Type M
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -10 - 60 °C
- Operating relative humidity (H-H)
- 0 - 80%
Weight & dimensions
- Weight
- 1.25 kg
- Receiver dimensions (WxDxH)
- 131 x 131 x 27 mm
- Transmitter dimensions (WxDxH)
- 131 x 131 x 27 mm
Packaging data
- Package width
- 367 mm
- Package depth
- 238 mm
- Package height
- 76 mm
- Package weight
- 2.2 kg
Packaging content
- AC adapter included
- Yes
- Cables included
- LAN (RJ-45)
- Quick start guide
- Yes
- Mounting brackets included
- Yes
Technical details
- Compliance certificates
- RoHS
- Audio support
- Yes
Logistics data
- Master (outer) case width
- 390 mm
- Master (outer) case length
- 491 mm
- Master (outer) case height
- 268 mm
- Products per master (outer) case
- 6 pc(s)
