This product is out of stock
We can email you when it's back in stock, confirm expected lead times, or recommend in-stock alternatives that meet the same requirements.
StarTech.com Rackmount KVM Console HD 1080p, Single Port VGA KVM with 17" LCD Monitor for Server Rack, Fully Featured 1U LCD KVM Drawer with Cables & Hardware, USB Support, 50,000 MTBF - 17in. LCD KVM Console (RKCONS17HD) - KVM console with KVM switch - 1 ports - USB - 17.3" - rack-mountable - 1920 x 1080 Full HD (1080p) @ 60 Hz - 300 cd/m� - 800:1 - VGA - black - 1U
- 43.9 cm (17.3") LCD 1920 x 1080 pixels 300 cd/m² 800:1
- Rack mounting 1U
- Mean time between failures (MTBF): 50000 h
- Video port type: VGA
- Steel
- Black
Similar Products
Overview
StarTech.com Rackmount KVM Console HD 1080p - Single Port VGA KVM with 17" LCD Monitor for Server Rack - Fully Featured 1U LCD KVM Drawer w/Cables & Hardware - USB Support - 50,000 MTBF
Specifications
Display
- Display diagonal
- 43.9 cm (17.3")
- Display resolution
- 1920 x 1080 pixels
- Display
- TFT LCD
- Display brightness
- 300 cd/m²
- Contrast ratio (typical)
- 800:1
- Viewing angle, horizontal
- 170°
- Viewing angle, vertical
- 170°
- Pixel pitch
- 0.1989 x 0.1989 mm
- Aspect ratio
- 16:9
- Display type
- LCD
- Display number of colours
- 262144 colours
- Colour depth
- 6 bit
Technical details
- Material
- Steel
- Mean time between failures (MTBF)
- 50000 h
- Product colour
- Black
- Operating relative humidity (H-H)
- 10 - 80%
- Rack mounting
- Yes
- Daisy chain
- No
- LED indicators
- Power, Status
- Cable length
- 1.8 m
- Compliance certificates
- RoHS
- Rack capacity
- 1U
- Audio support
- No
- IP control
- No
Ports & interfaces
- Video port type
- VGA
Keyboard
- Built-in touchpad
- Yes
Certificates
- Certification
- CE, FCC, PSE, UL, REACH
Power
- Power consumption (typical)
- 13 W
- AC adapter input voltage
- 100 - 240 V
- Input current
- 1.5 A
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -20 - 60 °C
Weight & dimensions
- Width
- 483 mm
- Height
- 565 mm
- Depth
- 43 mm
- Weight
- 11.2 kg
- Mounting depth (min)
- 51 cm
- Mounting depth (max)
- 85 cm
Packaging data
- Package weight
- 16 kg
- Package width
- 615 mm
- Package depth
- 765 mm
- Package height
- 185 mm
Group 8659
- Cables included
- KVM
- Screws included
- Yes
- Number of screws
- 8
- Cage nuts included
- Yes
- Number of cage nuts
- 8
- Included power plug types
- ANZ, EU, JP, NA, UK
- Quick installation guide
- Yes
Group 25021
- Master (outer) case width
- 615 mm
- Master (outer) case length
- 765 mm
- Master (outer) case height
- 185 mm
- Products per master (outer) case
- 1 pc(s)
