StarTech.com Thunderbolt 3 Dock, Dual 4K 60Hz Monitor TB3 Docking Station with DisplayPort, HDMI & 1080p VGA, 85W Power Delivery & Charging, Gigabit Ethernet, Universal Thunderbolt 3 Dock - TB3 Dock w/ 85W PD (TB3DK2DHVUE) - Docking station - Thunderbolt 3 - VGA, HDMI, 2 x DP - 1GbE
Manuf P/N: TB3DK2DHVUE
APAXON#: 4850569
EAN: 0065030876247
StarTech.com Thunderbolt 3 Dock, Dual 4K 60Hz Monitor TB3 Docking Station with DisplayPort, HDMI & 1080p VGA, 85W Power Delivery & Charging, Gigabit Ethernet, Universal Thunderbolt 3 Dock - TB3 Dock w/ 85W PD (TB3DK2DHVUE) - Docking station - Thunderbolt 3 - VGA, HDMI, 2 x DP - 1GbE
- Wired
- Host interface: Thunderbolt 3
- USB Power Delivery (USB PD)
- Ethernet LAN 10,100,1000 Mbit/s
- Auto MDI/MDI-X Full duplex
Stock14
Price £141.68
Quantity
|
Similar Products
Product Summary
StarTech.com Thunderbolt 3 Dock - Dual 4K 60Hz Monitor TB3 Laptop Docking Station with DisplayPort, HDMI & 1080p VGA - 85W Power Delivery & Charging - 2x USB-A, Ethernet - Mac & Windows
Extended Specification
Ports & interfaces
Connectivity technology
Wired
Host interface
Thunderbolt 3
USB 2.0 ports quantity
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
HDMI ports quantity
1
Microphone in
No
Headphone outputs
0
USB Power Delivery (USB PD)
Yes
USB Power Delivery up to
85 W
VGA (D-Sub) ports quantity
1
DisplayPorts quantity
2
DC-in jack
Yes
Network
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Ethernet LAN data rates
10,100,1000 Mbit/s
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Auto MDI/MDI-X
Yes
Full duplex
Yes
Performance
Product colour
Grey
Card reader integrated
No
HD type
4K Ultra HD
Maximum digital resolution
4096 x 2160 pixels
UASP support
Yes
Housing material
Aluminium
Certification
CE, FCC, REACH
Power
Power source type
AC
AC input voltage
100 - 240 V
Input current
1.8 A
Output voltage
19 V
Output current
6.32 A
Power consumption (typical)
120 W
Power plug type
Type N
Compatible power plug types
EU, UK
Software
Windows operating systems supported
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Mac operating systems supported
Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
20 - 80%
Weight & dimensions
Width
58.6 mm
Depth
196 mm
Height
24 mm
Weight
340 g
Packaging data
Package width
187 mm
Package depth
254 mm
Package height
65 mm
Package weight
1.3 kg
Packaging content
Cables included
AC, Thunderbolt
AC adapter included
Yes
Manual
Yes
Technical details
Compliance certificates
RoHS
Logistics data
Products per master (outer) case
20 pc(s)
Master (outer) case width
390 mm
Master (outer) case length
676 mm
Master (outer) case height
280 mm
Harmonized System (HS) code
84733020
Other features
Cable length
0.5 m
Chipset
Intel - Alpine Ridge JHL6540, Intel - WGI210AT, ASMedia - ASM1042A, Parade - PS176, Chrontel - CH7517
