StarTech.com USB C Multiport Adapter, HDMI 4K 30Hz or VGA Travel Dock, 5Gbps USB 3.0 Hub (USB A / USB C Ports), 100W Power Delivery, SD/MicroSD Slot, GbE, 12" (30cm) Long Attached Cable
Manuf P/N: DKT30CHVSDPD
APAXON#: 7254685
EAN: 0065030891769
StarTech.com USB C Multiport Adapter, HDMI 4K 30Hz or VGA Travel Dock, 5Gbps USB 3.0 Hub (USB A / USB C Ports), 100W Power Delivery, SD/MicroSD Slot, GbE, 12" (30cm) Long Attached Cable
USB C Mini Dock
Docking station
USB-C 3.2 Gen 1
HDMI, VGA
1GbE
Weight: 0.18 KG
USB C Mini Dock
Docking station
USB-C 3.2 Gen 1
HDMI, VGA
1GbE
Weight: 0.18 KG
- 9-IN-1 USB-C MULTIPORT ADAPTER: HDMI 4K 30Hz or VGA video (DP Alt Mode req); 2-Port USB-A USB 3.1 Gen 1 Hub 5Gbps including 1x BC 1.2 charge port; 1x USB-C 5Gbps port; 1x USB-C 100W PD 3.0 port; SD & MicroSD Card Readers; Gigabit Ethernet (PXE Boot & WoL)
- EXTRA LONG CABLE: USB C mini docking station with 12"" (30cm) attached cable for extended reach to reduce port/connector strain on 2-in-1 devices like Surface Pro 7, iPad Pro, HP Elite x2 & laptops on riser stands
- RELIABLE PERFORMANCE: USB bus powered or via external USB-C power adapter; 100W Power Delivery 3.0 pass through w/ 15W reserved for adapter to avoid video flickering, device dropouts or overdrawing power common in other hubs; up to 85W for laptop charging
- WIDE COMPATIBILITY: Fully compatible with USB-C laptops, Ultrabooks & Chromebooks, plus Thunderbolt 3/4 laptops from HP, Dell, Lenovo, MacBooks (Intel processor and M1 chip), and Surface; works w/ Windows, macOS, iPadOS, Android and ChromeOS
- PORTABLE & COMPACT: Portable, durable aluminum USB Type-C multiport adapter is designed for easy transport in a laptop bag for convenient on-the-go use between office, home office, shared office spaces, and business travel
- STARTECH.COM CONNECTIVITY TOOLS: Provided with the portable all-in-one USB Type-C adapter, the application improves performance and security, featuring MAC Address Changer, USB Event Monitoring, Windows Layout & Wi-Fi Auto Switch utilities
Stock10
Price £64.42
Quantity
|
Similar Products
StarTech.com USB C Multiport Adapter, HDMI 4K 30Hz or VGA Travel Dock, 5Gbps USB 3.0 Hub (USB A / USB C Ports), 100W Power Delivery, SD/MicroSD Slot, GbE, 12" (30cm) Long Attached Cable
Your Choice
English
United Kingdom
1
Personal computer
-10 - 70 °C GB
Stock
10
£64.42
StarTech.com USB C Multiport Adapter - USB-C Travel Dock to 4K HDMI, 3x USB 3.0 Hub, SD/SDHC, GbE, 60W PD 3.0 Pass-Through - USB Type-C/Thunderbolt 3 - Upgraded Version of DKT30CSDHPD (DKT30CSDHPD3) - Docking station - USB-C - 1GbE - for P/N: ARMPIVOTE2, FPPNEUSTND, MONSTADQI
Cheaper
English
United Kingdom
1
Personal computer
-10 - 85 °C GB
Stock
0
£0.00
StarTech.com USB C Dock, 4K Dual Monitor HDMI Display, Mini Laptop Docking Station, 100W Power Delivery Passthrough, GbE, 2-Port USB-A Hub, USB Type-C Multiport Adapter,3.3' Cable, Dual 4K - 4K Mini Laptop Dock (DK30C2HAGPD) - Docking station - USB-C - 2 x HDMI - 1GbE - for P/N: ARMBARDUO, ARMBARDUOV, ARMDUAL, ARMDUAL30, ARMDUALV, ARMSLIMDUO
Cheaper
English
United Kingdom
1
Personal computer
-20 - 70 °C GB
Stock
0
£0.00
StarTech.com Dual Monitor USB 3.0 Docking Station w/ DVI to VGA & HDMI Adapters, 5x USB 3.0 & Audio - Vertical DVI Dock for Mac & Windows (USB3SDOCKDD) - Docking station - USB - DVI - 1GbE - for P/N: ARMBARDUO, ARMDUAL, ARMDUAL30, ARMSLIMDUO, TB33A1C
Cheaper
English
United Kingdom
1
Personal computer
-20 - 60 °C GB
Stock
0
£0.00
StarTech.com Thunderbolt 3 Mini Dock - Portable Dual Monitor w/ DP 4K 60Hz - 2X USB-A Hub (3.2/2.0), GbE - 28cm Cable - TB3 Multiport Adapter - Mac/Windows�- Upgraded Version of TB3DKM2DP (TB3DKMDPL) - Docking station - Thunderbolt 3 - 2 x DP - 1GbE
Cheaper
English
United Kingdom
1
Personal computer
-20 - 70 °C GB
Stock
0
£0.00
Product Summary
This USB-C multiport adapter supports 4K 30Hz HDMI or 1080p VGA and turns your MacBook Pro, Dell XPS, or other USB-C laptops or tablet into a workstation, anywhere you go. The USB Type-C multiport adapter provides 4K HDMI or 1080p VGA video output, two USB 3.1 Gen 1 Type-A (5Gbps) ports (including 1x Fast Charge port), a single USB 3.1 Gen 1 Type-C (5Gbps) port, an SD/microSD card reader and a Gigabit Ethernet port, all through one connection to your laptop's USB-C or Thunderbolt 3/4 port. Plus, it offers advanced charging through USB Power Delivery 3.0 and an extra-long attached host cable for an extended reach to offer more set up flexibility.
Main Specifications
- Product Description
- StarTech.com USB C Multiport Adapter, HDMI 4K 30Hz or VGA Travel Dock, 5Gbps USB 3.0 Hub (USB A / USB C Ports), 100W Power Delivery, SD/MicroSD Slot, GbE, 12" (30cm) Long Attached Cable - USB C Mini Dock - docking station - USB-C 3.2 Gen 1 - HDMI, VGA - 1GbE
- Product Type
- Docking station
- Docking Interface
- USB-C 3.2 Gen 1
- Video Interfaces
- HDMI, VGA
- Dimensions (WxDxH)
- 5.9 cm x 1.4 cm
- Weight
- 137 g
- Colour
- Space grey
- Networking
- Gigabit Ethernet
- Manufacturer Warranty
- 3-year warranty
Enhance productivity
The portable docking station offers versatile video flexibility by connecting your laptop to a 4K 30Hz HDMI monitor (4096 x 2160p) or a 1080p (60Hz) VGA monitor (1920 x 1080) to create a powerful workstation. For added video flexibility, the dock also supports ultra-wide monitors.
Connect your devices
The USB-C to USB 3. 1 Gen 1 hub gives you two USB-A (5Gbps) ports and one USB-C (5Gpbs) port to connect your USB devices.
Built-in SD card reader
Access your multimedia content with ease. The multiport adapter provides direct access to your SD, SDHC and SDXC memory cards or microSD (uSD) cards.
Charge your laptop and peripherals
With support for USB PD 3. 0 (up to 100W), the USB Type-C multiport adapter lets you power and charge your laptop when a power adapter is connected to the USB-C power input port. Plus, one of the USB-A (5Gbps) ports supports BC 1. 2 fast charge to power your peripherals when the dock is connected to a USB-C power adapter. PD 3. 0 features Fast Role Swap to prevent USB, Ethernet and video disruption when you switch power sources (USB-C power adapter to bus power).
Reliable network connectivity
The Gigabit Ethernet port ensures reliable wired network access with support for PXE Boot and WoL.
Extended Specification
Ports & interfaces
Connectivity technology
Wired
Host interface
USB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 2.0 ports quantity
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
HDMI ports quantity
1
Microphone in
No
Headphone outputs
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
2
USB Power Delivery (USB PD)
Yes
USB Power Delivery revision
3.0
USB Power Delivery up to
100 W
VGA (D-Sub) ports quantity
1
USB Power Delivery up to
100 W W
Network
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Ethernet LAN data rates
10,100,1000 Mbit/s
Wake-on-LAN ready
Yes
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Full duplex
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s Mbit/s
Performance
Product colour
Grey
Card reader integrated
Yes
Compatible memory cards
MicroSD (TransFlash), SD, SDHC, SDXC
Data transfer rate
5 Gbit/s
HD type
4K Ultra HD
Maximum digital resolution
3840 x 2160 pixels
Maximum analog resolution
1920 x 1080 pixels
Number of displays supported
1
Maximum refresh rate
60 Hz
LED indicators
Activity, Speed
UASP support
Yes
Data transfer rate
5 Gbit/s Gbit/s
Maximum digital resolution
3840 x 2160 pixels pixels
Maximum analog resolution
1920 x 1080 pixels pixels
Maximum refresh rate
60 Hz Hz
Power
Power consumption (typical)
15 W
Power consumption (typical)
15 W W
Software
Windows operating systems supported
Windows 7 Ultimate x64, Windows 10, Windows 7 x64, Windows 10 Education, Windows 8, Windows 10 Education x64, Windows 7, Windows 8 Enterprise, Windows 10 Enterprise, Windows 7 Enterprise, Windows 8 Enterprise x64, Windows 10 Enterprise x64, Windows 7 Enterprise x64, Windows 8 Pro, Windows 10 Home, Windows 7 Home Basic, Windows 8 Pro x64, Windows 10 Home x64, Windows 7 Home Basic x64, Windows 8 x64, Windows 10 IOT Core, Windows 7 Home Premium, Windows 8.1, Windows 10 IoT Enterprise, Windows 7 Home Premium x64, Windows 8.1 Enterprise, Windows 10 Pro, Windows 7 Professional, Windows 8.1 Enterprise x64, Windows 10 Pro x64, Windows 7 Professional x64, Windows 8.1 Pro, Windows 10 x64, Windows 7 Starter, Windows 8.1 Pro x64, Windows 11, Windows 7 Starter x64, Windows 8.1 x64, Windows 11 x64, Windows 7 Ultimate
Mac operating systems supported
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 13.0 Ventura
Other operating systems supported
ChromeOS
Operational conditions
Operating temperature (T-T)
0 - 45 °C
Storage temperature (T-T)
-10 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
0 - 45 °C °C
Storage temperature (T-T)
-10 - 70 °C °C
Operating relative humidity (H-H)
10 - 90% %
Weight & dimensions
Width
326 mm
Depth
59 mm
Height
14 mm
Weight
137 g
Width
326 mm mm
Depth
59 mm mm
Height
14 mm mm
Weight
137 g g
Packaging data
Package width
110 mm
Package depth
59 mm
Package height
15 mm
Package width
110 mm mm
Package depth
59 mm mm
Package height
15 mm mm
Packaging content
Quick start guide
Yes
Technical details
Compliance certificates
CE, RoHS
Logistics data
Products per master (outer) case
30 pc(s)
Master (outer) case width
450 mm
Master (outer) case length
340 mm
Master (outer) case height
200 mm
Harmonized System (HS) code
84733020
Products per master (outer) case
30 pc(s) pc(s)
Master (outer) case width
450 mm mm
Master (outer) case length
340 mm mm
Master (outer) case height
200 mm mm
Other features
Cable length
0.3 m
Chipset
Realtek - RTL8153, Parade Technologies - PS176, VIA Tech - VL102, VIA Tech - VL817
Cable length
0.3 m m
Disclaimers
- Product data is provided by CNET, we do not warrant the accuracy and completeness of the material contained in this data sheet
