ASUS B850M MAX GAMING WIFI - Motherboard - micro ATX - Socket AM5 - AMD B850 Chipset - USB-C 3.2 Gen2, USB-C 3.2 Gen 1, USB 3.2 Gen 2, USB 3.2 Gen 1 - Wi-Fi 6, Bluetooth, Gigabit LAN - onboard graphics (CPU required) - HD Audio (8-channel)
Manuf P/N: 90MB1LL0-M0EAY0
APAXON#: 11808590
EAN: 4711636062343
ASUS B850M MAX GAMING WIFI - Motherboard - micro ATX - Socket AM5 - AMD B850 Chipset - USB-C 3.2 Gen2, USB-C 3.2 Gen 1, USB 3.2 Gen 2, USB 3.2 Gen 1 - Wi-Fi 6, Bluetooth, Gigabit LAN - onboard graphics (CPU required) - HD Audio (8-channel)
- AMD Socket AM5 AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
- PC micro ATX AMD B850 7.1 channels
- DDR5-SDRAM 4 DIMM Maximum internal memory: 256 GB
- HDD & SSD M.2, SATA III RAID support Number of storage drives supported: 7
- BIOS type: UEFI AMI 256 Mbit
- Gigabit Ethernet Wi-Fi Wi-Fi 6 (802.11ax) Bluetooth 5.4
UK Stock10
ConditionNew
Price £ 188.48
Price inc. VAT
£ 226.18
Quantity
|
Sales & Technical Enquiries
Phone: 0161 464 9941Email: sales@apaxon.co.uk
Similar Products
ASUS B850M MAX GAMING WIFI - Motherboard - micro ATX - Socket AM5 - AMD B850 Chipset - USB-C 3.2 Gen2, USB-C 3.2 Gen 1, USB 3.2 Gen 2, USB 3.2 Gen 1 - Wi-Fi 6, Bluetooth, Gigabit LAN - onboard graphics (CPU required) - HD Audio (8-channel)
Your Choice
—
—
—
—
Stock10
£188.48
Product Summary
ASUS B850M MAX GAMING WIFI AMD B850 Socket AM5 micro ATX
Extended Specification
Processor
Processor manufacturer
AMD
Processor socket
Socket AM5
Compatible processor series
AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Supported processor sockets
Socket AM5
Memory
Supported memory types
DDR5-SDRAM
Number of memory slots
4
Maximum internal memory
256 GB
Memory slots type
DIMM
Memory channels
Dual-channel
ECC сompatibility
ECC & Non-ECC
Unbuffered memory
Yes
Storage controllers
Supported storage drive interfaces
M.2, SATA III
Supported storage drive types
HDD & SSD
Number of HDDs supported
4
Number of storage drives supported
7
RAID support
Yes
RAID levels
0, 1, 5, 10
Graphics
Parallel processing technology support
Not supported
Internal I/O
USB 2.0 connectors
2
USB 3.2 Gen 1 (3.1 Gen 1) connectors
3
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
Number of SATA III connectors
4
S/PDIF out connector
Yes
Front panel audio connector
Yes
Front panel connector
Yes
ATX Power connector (24-pin)
Yes
CPU fan connector
Yes
Number of chassis fan connectors
4
Chassis intrusion connector
Yes
EPS power connector (8-pin)
Yes
Number of COM connectors
1
TPM connector
Yes
12V power connector
Yes
RGB LED pin header
Yes
Number of RGB LED pin headers
3
Rear panel I/O ports
USB 2.0 ports quantity
5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
Ethernet LAN (RJ-45) ports
1
VGA (D-Sub) ports quantity
0
HDMI ports quantity
1
DVI-D ports quantity
0
DisplayPorts quantity
1
Line-in
Yes
Microphone in
Yes
WiFi-AP antenna jack
1
Network
Wi-Fi
Yes
Ethernet LAN
Yes
Ethernet interface type
Gigabit Ethernet
Top Wi-Fi standard
Wi-Fi 6 (802.11ax)
Wi-Fi standards
Wi-Fi 6 (802.11ax)
Bluetooth
Yes
Bluetooth version
5.4
Features
Component for
PC
Motherboard form factor
micro ATX
Motherboard chipset family
AMD
Motherboard chipset
AMD B850
Audio output channels
7.1 channels
Product colour
Black
Cooling type
Passive
Windows operating systems supported
Windows 10 x64, Windows 11
Expansion slots
PCI Express x16 (Gen 4.x) slots
3
PCI Express x16 (Gen 5.x) slots
1
Number of M.2 (M) slots
3
1st M.2 largest key size
2280
1st M.2 highest PCI Express generation
5.0
2nd M.2 largest key size
2280
2nd M.2 highest PCI Express generation
4.0
3rd M.2 largest key size
2280
3rd M.2 highest PCI Express generation
3.0
BIOS
BIOS type
UEFI AMI
BIOS memory size
256 Mbit
Weight & dimensions
Width
244 mm
Depth
244 mm
Packaging content
Cables included
SATA
Antenna included
Yes
Screws included
Yes
