Compare APC UPS
Comparing 5 products side-by-side — specifications, pricing and stock. Showing APC products in the UPS category.
| Specification | |||||
|---|---|---|---|---|---|
| General | |||||
| Device Type | UPS - external | UPS - rack-mountable | UPS - external | — | UPS - rack-mountable / external |
| Battery | |||||
| Automatic battery test | Yes | Yes | Yes | Yes | Yes |
| Battery capacity | — | 108 VAh | — | 845 VAh | 505 VAh |
| Battery life (max) | 5 year(s) | 5 year(s) | 5 year(s) | 5 year(s) | 5 year(s) |
| Battery recharge time | 3 h | 5 h | 3 h | 1.5 h | 3 h |
| Battery technology | Sealed Lead Acid (VRLA) | Sealed Lead Acid (VRLA) | Sealed Lead Acid (VRLA) | Sealed Lead Acid (VRLA) | — |
| Cold start | Yes | — | Yes | Yes | Yes |
| Hot-swap battery | Yes | Yes | Yes | Yes | Yes |
| Replacement battery cartridge | — | — | — | APCRBC140 | — |
| Typical backup time at full load | 4.6 min | 5.9 min | — | 4 min | 4 min |
| Typical backup time at half load | 15.8 min | 19.4 min | — | 11.8 min | 11.8 min |
| Ports & interfaces | |||||
| AC outlet types | C13 coupler | C13 coupler | C13 coupler | C13 coupler, C19 coupler | C13 coupler, C19 coupler |
| AC outlets quantity | 6 AC outlet(s) | 4 AC outlet(s) | 8 AC outlet(s) | 10 AC outlet(s) | — |
| Ethernet LAN (RJ-45) ports | 1 | 0 | 1 | 0 | — |
| Number of output IEC jumpers | 2 | 2 | — | 2 | — |
| Power plug | C14 coupler | C14 coupler | C14 coupler | Hardwire | C20 coupler |
| Serial interface | — | Yes | — | Yes | Yes |
| Serial interface type | — | RS-232 | — | RJ-45 | RJ-45 |
| Serial ports quantity | — | 1 | 1 | — | — |
| SmartSlot | Yes | — | — | Yes | Yes |
| USB 2.0 ports quantity | — | — | 1 | — | — |
| USB port | Yes | — | Yes | Yes | Yes |
| Features | |||||
| Audible alarm modes | — | Low battery alarm, Overload alarm | Alarm when on battery, Low battery alarm, Overload alarm | — | Battery replacement |
| Audible alarm(s) | Yes | Yes | Yes | Yes | Yes |
| Auto-restart | Yes | Yes | Yes | Yes | Yes |
| Automatic Voltage Regulation (AVR) | Yes | Yes | Yes | — | Yes |
| Crest factor | — | — | — | 3:1 | 3:1 |
| Efficiency | 98% | — | — | 94.1% | 92% |
| Emergency Power Off (EPO) | — | — | — | Yes | Yes |
| Hold time (max) | — | 8 ms | — | — | — |
| Hold time (min) | — | 4 ms | — | — | — |
| Input frequency | 50/60 Hz | 50/60 Hz | 50/60 Hz | 40 - 70 Hz | 40 - 70 Hz |
| Input operation voltage (max) | 302 V | 302 V | 300 V | 275 V | 275 V |
| Input operation voltage (min) | 151 V | 151 V | 170 V | 100 V | 100 V |
| Noise level | 40 dB | 38 dB | 41 dB | 55 dB | 55 dB |
| Output frequency | — | — | 50/60 Hz | — | 50/60 Hz |
| Output frequency regulation | — | — | — | 50/60 Hz | — |
| Output operation voltage (max) | 240 V | — | 240 V | 240 V | 240 V |
| Output operation voltage (min) | 220 V | — | 220 V | 220 V | 220 V |
| Output power | 500 W | 280 W | 600 W | 4500 W | 2700 W |
| Output power capacity | 0.75 kVA | 0.45 kVA | 1 kVA | 5 kVA | 3 kVA |
| Output voltage Total Harmonic Distortion (THD) | — | — | 5% | 3% | 2% |
| Power protection features | — | — | — | — | Overload |
| Surge energy rating | 540 J | 320 J | 455 J | 480 J | 340 J |
| Surge protection | — | Yes | Yes | Yes | Yes |
| Surge protection features | — | Digital Subscriber Line (DSL), Fax, Modem, Network | — | — | — |
| Temperature voltage compensation | — | — | Yes | — | — |
| UPS topology | Line-Interactive | Line-Interactive | Line-Interactive | Double-conversion (Online) | Double-conversion (Online) |
| Waveform | Sine | Sine | Sine | Sine | Sine |
| Web-based management | — | — | Yes | — | — |
| Packaging data | |||||
| Bundled software | Powershute Serial Edition | — | — | — | — |
| Package depth | 499 mm | 589 mm | 595 mm | 960 mm | 871 mm |
| Package height | 301 mm | 164 mm | 376 mm | 330 mm | 246 mm |
| Package weight | 14.2 kg | 11.7 kg | 19.6 kg | 66.9 kg | 39.3 kg |
| Package width | 278 mm | 476 mm | 328 mm | 610 mm | 599 mm |
| Resource CD | — | — | Yes | — | — |
| Software CD | — | Yes | Yes | — | — |
| Temperature sensor | — | — | — | Yes | — |
| Warranty card | — | — | — | Yes | — |
| Design | |||||
| Cable length | 1.83 m | — | — | — | 2.44 m |
| Display type | LCD | — | LCD | LCD | LCD |
| Form factor | Tower | Rackmount/Tower | Mini Tower | Rackmount | Rackmount |
| International Protection (IP) code | — | — | — | — | IP20 |
| LED indicators | Status | Battery replacement | Yes | — | Battery replacement |
| Product colour | Black | Grey | Black | Black | Black |
| Rack capacity | — | 1U | — | 3U | 2U |
| Packaging content | |||||
| Cables included | USB cable | RS-232 | USB cable | — | — |
| Manual | Yes | Yes | — | — | — |
| Quick installation guide | Yes | — | — | Yes | Yes |
| Rack mount kit | — | Yes | — | Yes | — |
| Certificates | |||||
| Certification | CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, UL 1778, VDE, REACH, PEP, EOLI | C-tick, CE, GOST, VDE, PEP, EOLI | CE, CSA, GOST, UL 1778, VDE | REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE | CE, VDE, RCM, EAC, IEC/EN 62040-1, IEC/EN 62040-2, UL-1778, FCC 15 A, CSA |
| Compliance certificates | RoHS | RoHS | — | RoHS | — |
| Weight & dimensions | |||||
| Depth | 358 mm | 383 mm | 439 mm | 719 mm | 635 mm |
| Height | 157 mm | 44 mm | 219 mm | 130 mm | 85 mm |
| Weight | 13.2 kg | 10.2 kg | 17.3 kg | 54.4 kg | 31.3 kg |
| Width | 138 mm | 432 mm | 171 mm | 432 mm | 432 mm |
| Compatibility Information | |||||
| Designed For | — | P/N: ACCS1000, ACCS1001, ACCS1002, ACCS1003, ACCS1004, ACCS1005, ACCS1006, ACCS1007, ACDC1015, ACDC1016, ACDC1017, ACDC1019, ACDC1020, ACDC1021, ACDC2513, ACF001, ACF002, ACF003, ACF101BLK, ACF102BLK, ACF201BLK, ACF400, ACF600, AP5017, AP5602, AP5606, AP5607, AP5616, AP92200, AP9290, AR100, AR100HD, AR106SH6, AR109SH6, AR112SH6, AR202, AR203A, AR204A, AR2101, AR2102BLK, AR2144BLK, AR2145BLK, AR2200, AR2280, AR2400, AR2400FP1, AR2401, AR2407, AR2480, AR2487, AR2487G, AR2500, AR2507, AR2580, AR2587, AR2900, AR2901, AR3000, AR3003, AR3003SP, AR3006, AR3006SP, AR3100, AR3100G, AR3100SP, AR3100SP1, AR3100SP2, AR3100TAA, AR3100W, AR3100X609, AR3100X610, AR3100X617, AR3101, AR3103, AR3103SP, AR3104SP1, AR3105, AR3105SP, AR3105W, AR3106, AR3106SP, AR3107, AR3107G, AR3107SP, AR3107X609, AR3107X610, AR3107X617, AR3130, AR3140, AR3140G, AR3140W, AR3150, AR3150SP, AR3150SP1, AR3150SP2, AR3150W, AR3150X609, AR3150X610, AR3150X617, AR3155, AR3155SP, AR3155W, AR3157, AR3157SP, AR3157X609, AR3157X610, AR3157X617, AR3200, AR3300, AR3300G, AR3300SP, AR3300W, AR3300X609, AR3300X610, AR3300X617, AR3305, AR3305SP, AR3305W, AR3307, AR3307SP, AR3307W, AR3307X609, AR3307X610, AR3307X617, AR3340, AR3340G, AR3340W, AR3347, AR3350, AR3350SP, AR3350W, AR3350X609, AR3350X610, AR3350X617, AR3355, AR3355SP, AR3355W, AR3357, AR3357SP, AR3357X609, AR3357X610, AR3357X617, AR3357X674, AR3810, AR3812, AR3814, AR4018, AR4018A, AR4018I, AR4018IA, AR4018IX429, AR4018IX431, AR4018IX432, AR4018SP, AR4018SPX429, AR4018SPX431, AR4018SPX432, AR4018X429, AR4018X431, AR4018X432, AR4024, AR4024A, AR4024I, AR4024IA, AR4024IX429, AR4024IX431, AR4024IX432, AR4024SP, AR4024SPX429, AR4024SPX431, AR4024SPX432, AR4024X429, AR4024X431, AR4024X432, AR4038, AR4038A, AR4038I, AR4038IA, AR4038IX429, AR4038IX431, AR4038IX432, AR4038X429, AR4038X431, AR4038X432, AR7007, AR7050, AR7057, AR8135BLK, NBWL0356A | — | — | — |
| Logistics data | |||||
| Harmonized System (HS) code | 85078000 | 85078000 | 85078000 | 85078000 | 85078000 |
| Products per pallet | 24 pc(s) | 24 pc(s) | 18 pc(s) | 6 pc(s) | 6 pc(s) |
| Total carbon footprint (kg of CO2e) | 639.93 | 484.92 | 853.59 | 8408.59 | 4988.41 |
| Power Device | |||||
| Input Voltage | AC 220/230/240 V | AC 230 V | AC 220/230/240 V | — | AC 220/230/240 V |
| Input Voltage Range | AC 160 - 286 V | AC 160 - 286 V | AC 180 - 286 V | — | AC 160 - 275 V |
| Power Capacity | 500 Watt / 750 VA | 280 Watt / 450 VA | 600 Watt / 1000 VA | — | 2700 Watt / 3000 VA |
| Other features | |||||
| Nominal output voltage | — | 230 V | — | — | — |
| Output voltage | — | — | — | — | 230 V |
| Packaging content | — | — | — | Web/SNMP Management Card | — |
| Operational conditions | |||||
| Non-operating altitude | 0 - 15000 m | 0 - 15000 m | 0 - 15000 m | 0 - 15000 m | 0 - 15000 m |
| Operating altitude | 0 - 3000 m | 0 - 3000 m | 0 - 3000 m | 0 - 3000 m | 0 - 3000 m |
| Operating relative humidity (H-H) | 5 - 95% | 0 - 95% | 0 - 95% | 0 - 95% | 0 - 95% |
| Operating temperature (T-T) | 0 - 40 °C | 0 - 40 °C | 0 - 40 °C | 0 - 40 °C | 0 - 40 °C |
| Storage relative humidity (H-H) | 0 - 95% | 0 - 95% | 0 - 95% | 0 - 95% | 0 - 95% |
| Storage temperature (T-T) | -15 - 45 °C | -15 - 45 °C | -15 - 45 °C | -15 - 45 °C | -15 - 45 °C |
| Sustainability | |||||
| Sustainability certificates | Green Premium | — | Green Premium | ENERGY STAR | Green Premium |
