APC Smart-UPS SRT 3000VA RM
Thumbnail 0
Thumbnail 1
Thumbnail 2
Thumbnail 3
Thumbnail 4
Thumbnail 5
Thumbnail 6
Thumbnail 7
Thumbnail 8
Thumbnail 9

APC Smart-UPS SRT 3000VA RM

Manuf P/N: SRT3000RMXLI-NC
APAXON#: 3938617
EAN: 731304327592
APC Smart-UPS SRT 3000VA RM
UPS (rack-mountable / external)
AC 220/230/240 V
2700 Watt
3000 VA
Lead Acid
RS-232, USB
output connectors: 10
2U
black
with APC UPS Network Management Card AP9641
for P/N: AR4018SPX432, AR4024SP, AR4024SPX429, AR4024SPX431, AR4024SPX432, NBWL0356A
Weight: 46.00 KG
  • Battery failure notification
  • ECO mode
  • Green mode
  • LCD graphics display
  • Rack/Tower convertible
Stock56
Price £ 3,693.64
Price inc. VAT
£ 4,432.37
Quantity
|

Product Summary

Provides early-warning fault analysis on batteries enabling timely preventive maintenance. ECO mode by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection. Green mode bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection. Text and mimic diagrams display modes of operation, system parameters and alarms. Protects the initial investment in the UPS when migrating from tower to rack-mount environment.

Extended Specification

Features
UPS topology
Double-conversion (Online)
Output power capacity
3 kVA
Output power
2700 W
Waveform
Sine
Input operation voltage (min)
100 V
Input operation voltage (max)
275 V
Input frequency
40 - 70 Hz
Output operation voltage (min)
220 V
Output operation voltage (max)
240 V
Output frequency
50/60 Hz
Automatic Voltage Regulation (AVR)
Yes
Surge energy rating
340 J
Efficiency
92%
Crest factor
3:1
Emergency Power Off (EPO)
Yes
Output voltage Total Harmonic Distortion (THD)
2%
Noise level
55 dB
Surge protection
Yes
Power protection features
Overload
Audible alarm(s)
Yes
Audible alarm modes
Battery replacement
Auto-restart
Yes
Output power capacity
3 kVA kVA
Output power
2700 W W
Input operation voltage (min)
100 V V
Input operation voltage (max)
275 V V
Input frequency
40 - 70 Hz Hz
Output operation voltage (min)
220 V V
Output operation voltage (max)
240 V V
Output frequency
50/60 Hz Hz
Surge energy rating
340 J J
Efficiency
92% %
Output voltage Total Harmonic Distortion (THD)
2% %
Noise level
55 dB dB
Ports & interfaces
AC outlet types
C13 coupler, C19 coupler
Power plug
C20 coupler
USB port
Yes
Serial interface
Yes
Serial interface type
RJ-45
SmartSlot
Yes
Battery
Battery technology
Sealed Lead Acid (VRLA)
Battery capacity
505 VAh
Typical backup time at full load
4 min
Typical backup time at half load
11.8 min
Battery life (max)
5 year(s)
Battery recharge time
3 h
Hot-swap battery
Yes
Automatic battery test
Yes
Cold start
Yes
Battery capacity
505 VAh VAh
Typical backup time at full load
4 min min
Typical backup time at half load
11.8 min min
Battery life (max)
5 year(s) year(s)
Battery recharge time
3 h h
Design
Form factor
Rackmount
Product colour
Black
Rack capacity
2U
Cable length
2.44 m
Display type
LCD
LED indicators
Battery replacement
International Protection (IP) code
IP20
Cable length
2.44 m m
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-15 - 45 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3000 m
Non-operating altitude
0 - 15000 m
Operating temperature (T-T)
0 - 40 °C °C
Storage temperature (T-T)
-15 - 45 °C °C
Operating relative humidity (H-H)
0 - 95% %
Storage relative humidity (H-H)
0 - 95% %
Operating altitude
0 - 3000 m m
Non-operating altitude
0 - 15000 m m
Certificates
Compliance certificates
RoHS
Certification
CE, VDE, RCM, EAC, IEC/EN 62040-1, IEC/EN 62040-2, UL-1778, FCC 15 A, CSA
Packaging content
Quick installation guide
Yes
Sustainability
Sustainability certificates
Green Premium
Weight & dimensions
Width
432 mm
Depth
635 mm
Height
85 mm
Weight
31.3 kg
Width
432 mm mm
Depth
635 mm mm
Height
85 mm mm
Weight
31.3 kg kg
Packaging data
Package width
599 mm
Package depth
871 mm
Package height
246 mm
Package weight
39.3 kg
Package width
599 mm mm
Package depth
871 mm mm
Package height
246 mm mm
Package weight
39.3 kg kg
Logistics data
Products per pallet
6 pc(s)
Harmonized System (HS) code
85078000
Total carbon footprint (kg of CO2e)
4988.41
Products per pallet
6 pc(s) pc(s)
Other features
Output voltage
230 V
Output voltage
230 V V
Power Device
Input Voltage
AC 220/230/240 V
Power Capacity
2700 Watt / 3000 VA
Input Voltage Range
AC 160 - 275 V
General
Device Type
UPS - rack-mountable / external
APC Smart-UPS SRT 3000VA RM
