Compare EATON UPS
Comparing 5 products side-by-side — specifications, pricing and stock. Showing EATON products in the UPS category.
| Specification | EATON Eaton Ellipse PRO 650 - UPS - AC 230 V - 400 Watt - 650 VA - 7 Ah - USB - output connectors: 4 - 2U - 19"ELP650IEC £167.70 £201.24 inc VAT | ||||
|---|---|---|---|---|---|
| General | |||||
| Colour | Black, silver | — | — | — | — |
| Device Type | UPS - rack-mountable | — | UPS - external | — | — |
| Height (Rack Units) | 1U | — | 2U | — | — |
| Rack Size | 19" | — | 19" | — | — |
| Battery | |||||
| Capacity | 9 Ah | — | 7 Ah | — | — |
| Features | Maintenance free | — | — | — | — |
| Quantity | 4 | — | 2 | — | — |
| Run Time (Up To) | — | — | 9 min at half load, 5 min at 70% load | — | — |
| Technology | Lead Acid | — | Lead Acid | — | — |
| Voltage Provided | 6 V | — | — | — | — |
| Network | |||||
| Remote Management Interface | RS-232, USB, RJ-45 | — | USB | — | — |
| Miscellaneous | |||||
| Cables Included | USB cable - external, 2 x power cable (IEC) - external, AC input cable (BS 1363) - external | — | USB cable - external | — | — |
| Compliant Standards | — | — | CB, IEC 62040-1-1, IEC 62040-2, IEC 61643-1, EN 62040-1-1, EN 62040-2 | — | — |
| Features | LVD, CB, EMC, RoHS, WEEE, IEC/EN 62040-1, IEC/EN 62040-2, IEC/EN 62040-3, UL 1778, CAN/CSA-C22.2, UKCA, CM, UKR, KCC, cTUVus, BIS | — | Wall mountable, LCD display, Automatic Voltage Regulation (AVR), deep discharge protection, cold-start function, EcoControl Master/Control outlets | — | — |
| Included Accessories | Cable locking system, network management card | — | — | — | — |
| Rack Mounting Kit | Included | — | Optional | — | — |
| Power Device | |||||
| Circuit Protection | — | — | Circuit breaker | — | — |
| Dataline Surge Protection | — | — | Network/phone line - RJ-45/RJ-11 - 1 input line / 1 output line | — | — |
| Efficiency | 98.2% | — | — | — | — |
| Frequency Provided | 50/60 Hz | — | 50/60 Hz | — | — |
| Frequency Required | 47 - 70 Hz | — | 50/60 Hz | — | — |
| Input Connectors | 1 x power IEC 60320 C14 | — | 1 x power IEC 60320 C14 | — | — |
| Input Voltage | AC 200/208/220/230/240 V | — | AC 230 V | — | — |
| Input Voltage Range | AC 160 - 294 V | — | AC 165 - 285 V | — | — |
| Input Voltage Range (Adjustable) | AC 150 - 294 V | — | AC 150 - 285 V | — | — |
| Input Wiring | 1-phase | — | — | — | — |
| Output Voltage | AC 200/208/220/230/240 V + 6% / - 10% - 50/60 Hz | — | AC 220/230/240 V + 15% / - 20% - 50/60 Hz | — | — |
| Output Waveform | Sinewave | — | — | — | — |
| Power Capacity | 920 Watt / 1150 VA | — | 750 Watt / 1200 VA | — | — |
| Power Output Connectors Details | 6 x power IEC 60320 C13 | — | 4 x power IEC 60320 C13 (UPS and surge), 4 x power IEC 60320 C13 (surge) | — | — |
| Surge Suppression | — | — | Yes | — | — |
| UPS Technology | Line interactive | — | Line interactive | — | — |
| Weight & dimensions | |||||
| Depth | 50.9 cm | — | 39 cm | — | — |
| Height | 4.32 cm | — | 27.5 cm | — | — |
| Weight | 14.54 kg | — | 9.9 kg | — | — |
| Width | 43.8 cm | — | 8.2 cm | — | — |
| Connections & Expansion | |||||
| Expansion Slots | 1 (total) / 0 (free) x Communication slot | — | — | — | — |
| Interfaces | 1 x management (RS-232) - RJ-45, 1 x management (USB), 1 x remote power (on/off) - mini terminal block, Dry contact | — | 1 x management (USB) - 4 pin USB Type B | — | — |
| Environmental Parameters | |||||
| Humidity Range Operating | 0 - 90% (non-condensing) | — | 0 - 85% | — | — |
| Max Operating Temperature | 40 °C | — | 35 °C | — | — |
| Min Operating Temperature | 0 °C | — | 0 °C | — | — |
| Sound Emission | 35 dB | — | — | — | — |
| Manufacturer Warranty | |||||
| Service & Support | Limited warranty - electronics - 3 years, Limited warranty - batteries - 2 years | — | Limited warranty - 3 years, Limited warranty - batteries - 3 years | — | — |
| Software / System Requirements | |||||
| Software Included | — | — | Eaton UPS Companion | — | — |
