Compare STARTECH Portable Docking stations
Comparing 5 products side-by-side — specifications, pricing and stock. Showing STARTECH products in the Portable Docking stations category.
| Specification | |||||
|---|---|---|---|---|---|
| General | |||||
| Docking Interface | USB-C | USB | USB | USB | — |
| Optical Storage | — | — | None | — | — |
| Product Type | Docking station | Docking station | Docking station | Docking station | — |
| Video Interfaces | 2 x DP, HDMI | VGA, HDMI | 2 x HDMI, 2 x DP | HDMI, DP | — |
| Power | |||||
| AC input voltage | 100 - 240 V | 100-240 V | — | 100-240 V | 100 - 240 V |
| Compatible power plug types | EU, UK | AU, EU, UK, US | EU, UK | AU, EU, UK, US | AU, EU, UK, US |
| Input current | — | 0.9 A | — | 1.5 A | 0.8 A |
| Output current | — | 4 A | — | 6.5 A | 4 A |
| Output voltage | — | 5 V | — | 5 V | 5 V |
| Power consumption (typical) | — | 20 W | — | 32.5 W | 20 W |
| Power plug type | Type M | Type B | — | — | Type M |
| Power source type | — | — | — | — | AC |
| Network | |||||
| Auto MDI/MDI-X | — | Yes | — | Yes | Yes |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T | 1000BASE-T, 100BASE-TX, 10BASE-T | — | — | — |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet | Ethernet | — | Ethernet, Fast Ethernet, Gigabit Ethernet | — |
| Ethernet LAN | Yes | Yes | Yes | Yes | Yes |
| Ethernet LAN (RJ-45) ports | 1 | 1 | 1 | 1 | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s | 10,100,1000 Mbit/s | — | 10,100,1000 Mbit/s | 10,100,1000 Mbit/s |
| Full duplex | — | Yes | — | Yes | Yes |
| Networking standards | IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u | — | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Wake-on-LAN ready | — | — | — | Yes | Yes |
| Packaging content | |||||
| AC adapter included | Yes | Yes | — | Yes | Yes |
| Cables included | USB Type-C to USB Type-C | USB | USB | AC, USB | USB |
| Drivers included | — | Yes | — | Yes | Yes |
| Interface adapters included | — | — | — | — | DVI-I male - HDMI female, DVI-I male - VGA female |
| Manual | — | Yes | — | Yes | Yes |
| Quick start guide | Yes | — | Yes | — | — |
| Stand included | — | — | — | — | Yes |
| Performance | |||||
| Brand compatibility | — | — | — | Any brand | Any brand |
| Cable lock slot | Yes | Yes | — | Yes | — |
| Cable lock slot type | — | Kensington | — | — | — |
| Card reader integrated | Yes | No | No | No | No |
| Certification | CE, FCC, RoHS | FCC, CE, TAA, REACH | CE, FCC | CE, FCC, DisplayLink | CE, FCC, REACH |
| Charging function | — | — | — | Yes | Yes |
| Compatible memory cards | MMC, SD | — | — | — | — |
| Data transfer rate | 10 Gbit/s | 5 Gbit/s | 10 Gbit/s | 5 Gbit/s | 5 Gbit/s |
| HD type | 4K Ultra HD | — | — | — | — |
| Housing material | — | Plastic | Aluminium, Plastic | Plastic, Steel | Aluminium, Plastic |
| LED indicators | Yes | — | — | Activity, Link | Power |
| Maximum analog resolution | — | 2048 x 1152 pixels | — | — | 2048 x 1152 pixels |
| Maximum digital resolution | 3840 x 2160 pixels | 1920 x 1200 pixels | 3840 x 2160 pixels | 3840 x 2160 pixels | — |
| Maximum refresh rate | 60 Hz | — | — | — | — |
| Number of displays supported | 3 | — | 2 | — | — |
| Product colour | Black, Grey | Black | Black, Grey | Black | Black, Silver |
| Rubber feet | — | — | — | — | Yes |
| UASP support | — | — | — | Yes | Yes |
| Other features | |||||
| Cable length | — | — | — | 0.6 m | 1 m |
| Chipset | Cypress - CYPD4236, Synaptics - VMM5320BJG-R | DisplayLink - DL-3900, Genesys Logic - GL3520, Realtek - RTL8211E | DL-6950 | DisplayLink - DL-5900, VLI - VL812 | DisplayLink - DL-3900, Genesys Logic - GL3520 |
| USB data transfer rates | — | 12,480,5000 Mbit/s | — | 5000 Mbit/s | 12,480,5000 Mbit/s |
| Ports & interfaces | |||||
| Combo headphone/mic port | Yes | — | Yes | — | Yes |
| Connectivity technology | Wired | Wired | Wired | Wired | Wired |
| DC-in jack | Yes | Yes | — | — | Yes |
| DisplayPort version | 1.4 | — | — | — | — |
| DisplayPorts quantity | 2 | — | 1 | 1 | — |
| DVI-D ports quantity | — | 1 | — | — | 1 |
| DVI-I ports quantity | — | — | — | — | 1 |
| HDMI ports quantity | 1 | 1 | 2 | 1 | 0 |
| HDMI version | 2.0 | — | — | — | — |
| Headphone connectivity | 3.5 mm | — | — | 3.5 mm | 3.5 mm |
| Headphone outputs | 1 | 1 | 1 | 1 | 1 |
| Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C | USB 3.2 Gen 1 (3.1 Gen 1) Type-B | USB 3.2 Gen 1 (3.1 Gen 1) Type-B | USB 3.2 Gen 1 (3.1 Gen 1) Type-B | USB 3.2 Gen 1 (3.1 Gen 1) Type-B |
| Microphone in | — | Yes | — | — | — |
| USB 2.0 ports quantity | 2 | 0 | 0 | 0 | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 | 3 | 6 | 4 | 5 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 | — | — | — | — |
| USB connector type | — | — | — | USB Type-A | — |
| USB Power Delivery (USB PD) | Yes | — | — | — | — |
| USB Power Delivery up to | 100 W | — | — | — | — |
| VGA (D-Sub) ports quantity | — | 1 | — | — | — |
| Technical details | |||||
| Compliance certificates | — | RoHS | RoHS | RoHS | RoHS |
| Weight & dimensions | |||||
| Depth | 90 mm | 304 mm | 73 mm | 227 mm | 83 mm |
| Height | 30 mm | 44 mm | 187 mm | 24 mm | 178 mm |
| Weight | 300 g | 295 g | 347 g | 277 g | 285 g |
| Width | 210 mm | 178 mm | 135 mm | 76 mm | 23 mm |
| Logistics data | |||||
| Harmonized System (HS) code | 84733020 | 84733020 | 84733020 | 84733020 | 84733020 |
| Master (outer) case height | 195 mm | 345 mm | 300 mm | 302 mm | 251 mm |
| Master (outer) case length | 282 mm | 435 mm | 340 mm | 426 mm | 415 mm |
| Master (outer) case width | 390 mm | 215 mm | 220 mm | 390 mm | 357 mm |
| Products per master (outer) case | 4 pc(s) | 6 pc(s) | 6 pc(s) | 10 pc(s) | 10 pc(s) |
| Products per shipping (inner) case | — | — | — | 150 pc(s) | — |
| Software | |||||
| Linux operating systems supported | — | — | Yes | — | — |
| Mac compatibility | — | Yes | — | Yes | Yes |
| Mac operating systems supported | — | Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 13.0 Ventura | Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 13.0 Ventura | Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 13.0 Ventura |
| Mobile operating systems supported | Android 10, Android 9.0, iPadOS | — | — | — | — |
| Other operating systems supported | ChromeOS | ChromeOS | ChromeOS | ChromeOS | ChromeOS |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64 | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 2000, Windows 2000 Professional, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64 | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64 |
| Operational conditions | |||||
| Operating relative humidity (H-H) | — | 0 - 90% | 0 - 95% | 0 - 90% | 5 - 85% |
| Operating temperature (T-T) | — | 0 - 40 °C | 0 - 50 °C | 0 - 40 °C | 0 - 50 °C |
| Storage temperature (T-T) | — | -10 - 60 °C | -20 - 70 °C | -10 - 80 °C | -20 - 60 °C |
| Packaging data | |||||
| Package depth | 150 mm | 296 mm | 109 mm | 198 mm | 186 mm |
| Package height | 94 mm | 66 mm | 142 mm | 71 mm | 95 mm |
| Package weight | 1.4 kg | 878 g | 800 g | 1.1 kg | 1.02 kg |
| Package width | 270 mm | 195 mm | 210 mm | 251 mm | 255 mm |
