Compare STARTECH Portable Docking stations
Comparing 5 products side-by-side — specifications, pricing and stock. Showing STARTECH products in the Portable Docking stations category.
| Specification | |||||
|---|---|---|---|---|---|
| Power | |||||
| AC input voltage | 100 - 240 V | 100 - 240 V | — | 110 - 240 V | — |
| Compatible power plug types | EU, UK | EU, UK | — | EU, UK | — |
| Input current | 2.5 A | 1.5 A | — | 2.5 A | — |
| Output current | 8.5 A | 4.5 A | — | 9 A | — |
| Output voltage | 20 V | 20 V | — | 20 V | — |
| Power consumption (max) | — | — | — | 180 W | — |
| Power consumption (typical) | 170 W | 100 W | 15 W | — | — |
| Power plug type | Type N | Type N | — | — | — |
| Power source type | — | AC | USB | DC | — |
| Power supply | 100 W | — | — | — | — |
| USB cable length | — | — | 0.6 m | — | — |
| Wireless charging | — | — | — | — | No |
| Network | |||||
| 10G support | No | — | — | — | — |
| Auto MDI/MDI-X | — | Yes | — | — | — |
| Copper ethernet cabling technology | — | — | — | 2.5GBASE-T, 10BASE-T, 100BASE-T, 1000BASE-T | — |
| Ethernet LAN | Yes | Yes | Yes | Yes | Yes |
| Ethernet LAN (RJ-45) ports | 1 | 1 | 1 | 1 | 1 |
| Ethernet LAN data rates | — | 10,100,1000 Mbit/s | 10,100,1000 Mbit/s | 10,100,1000,2500 Mbit/s | 10,100,1000 Mbit/s |
| Full duplex | Yes | Yes | Yes | Yes | — |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u | — | IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u |
| Wake-on-LAN ready | — | — | Yes | — | Yes |
| Packaging content | |||||
| AC adapter included | Yes | Yes | — | Yes | — |
| Cables included | USB Type-A to USB Type-C | USB Type-C | — | Thunderbolt | — |
| Manual | — | — | — | — | Yes |
| Quick start guide | Yes | Yes | Yes | Yes | — |
| Other features | |||||
| Cable length | — | — | — | — | 0.28 m |
| Chipset | DisplayLink - DL6950, Genesys Logic - GL3523, Fresco Logic - FL7102, Fresco Logic - FL7201, VIA Labs - VL160, RealTek - RTL8153, Texas Instruments - TS3A225E | VIA/VLI - VL813, MegaChips - STDP4320, Realtek - RTL8153, C-Media - CM6533, Texas Instruments - TPS65983 | Parade - PS8469, Synaptics - VMM5322, VIA - VL822, VIA - VL103, Realtek - RTL8153 | Intel - JHL8440, Cypress - HX3PD, Parade - FL5801, Realtek - RTL8156BG, Genesys Logic - GL3231S, Realtek - ALC4030U, Realtek - RTD2188, Cypress - CCG5, TI - TPS2546 | Intel JHL6540 (Alpine Ridge), Texas Instruments TPS65983A, Parade PS176, ASMedia ASM1042A, Intel WGI210 |
| Performance | |||||
| Cable lock slot | Yes | — | — | Yes | — |
| Cable lock slot type | Kensington | — | — | Kensington, Nano | — |
| Card reader integrated | No | No | No | Yes | No |
| Certification | CE, FCC, REACH | — | — | — | — |
| Compatible memory cards | — | — | — | MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD, SDHC, SDXC | — |
| Data transfer rate | 5 Gbit/s | 5 Gbit/s | 10 Gbit/s | 40 Gbit/s | 5 Gbit/s |
| HD type | — | — | 4K Ultra HD | 8K Ultra HD | — |
| Housing material | Plastic | Plastic | Plastic | Aluminium | Aluminium, Plastic |
| LED indicators | — | — | Yes | LAN, Power | — |
| Maximum digital resolution | 5120 x 2880 pixels | 4096 x 2160 pixels | 3840 x 2160 pixels | 7680 x 4320 pixels | 3840 x 2160 pixels |
| Maximum refresh rate | — | — | 60 Hz | 60 Hz | — |
| Number of displays supported | — | — | 3 | — | 2 |
| On/off switch | Yes | — | — | Yes | — |
| Plug and Play | — | Yes | — | — | — |
| Product colour | Black, Grey | Black, Silver | Grey | Grey | Grey |
| UASP support | Yes | Yes | Yes | Yes | — |
| Ports & interfaces | |||||
| Combo headphone/mic port | Yes | Yes | — | Yes | — |
| Connectivity technology | Wired | Wired | Wired | Wired | Wired |
| DC-in jack | Yes | — | — | Yes | No |
| DisplayPort version | — | — | 1.4 | 1.4 | — |
| DisplayPorts quantity | 2 | — | 2 | 2 | 2 |
| HDMI ports quantity | 2 | 2 | 2 | 2 | 0 |
| HDMI version | — | — | 2.0b | 2.1 | — |
| Headphone connectivity | 3.5 mm | 3.5 mm | — | 3.5 mm | — |
| Headphone outputs | 1 | 1 | 0 | 1 | 0 |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C | USB 3.2 Gen 1 (3.1 Gen 1) Type-C | USB 3.2 Gen 2 (3.1 Gen 2) Type-C | Thunderbolt 4 | Thunderbolt 3 |
| Microphone in | — | — | No | — | No |
| USB 2.0 ports quantity | 0 | 0 | 0 | 1 | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 | 4 | 0 | 2 | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 | 1 | 1 | — | — |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | — | — | 3 | 3 | — |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | — | — | — | 1 | — |
| USB Power Delivery (USB PD) | — | Yes | Yes | Yes | — |
| USB Power Delivery revision | — | 2.0 | 3.0 | 3.0 | — |
| USB Power Delivery up to | — | 60 W | 100 W | 98 W | — |
| Technical details | |||||
| Compliance certificates | RoHS | CE, RoHS | CE, Federal Communications Commission (FCC), RoHS | CE, RoHS | CE, RoHS |
| Weight & dimensions | |||||
| Depth | 220 mm | 220 mm | 122 mm | 96 mm | 124 mm |
| Height | 30 mm | 24 mm | 18 mm | 34 mm | 27 mm |
| Weight | 280 g | 259 g | 113 g | 200 g | 147.8 g |
| Width | 80 mm | 80 mm | 56 mm | 210 mm | 69 mm |
| Logistics data | |||||
| Harmonized System (HS) code | 84733020 | 84733020 | — | — | 84733020 |
| Master (outer) case height | 302 mm | 304 mm | 235 mm | 285 mm | 270 mm |
| Master (outer) case length | 335 mm | 337 mm | 530 mm | 310 mm | 437 mm |
| Master (outer) case width | 280 mm | 287 mm | 290 mm | 380 mm | 300 mm |
| Products per master (outer) case | 6 pc(s) | 6 pc(s) | 24 pc(s) | 4 pc(s) | 24 pc(s) |
| Software | |||||
| Mac compatibility | Yes | — | — | — | — |
| Mac operating systems supported | Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 13.0 Ventura | — | — | Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
| Other operating systems supported | ChromeOS | — | ChromeOS | — | — |
| Server operating systems supported | — | — | — | — | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 x64 |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64 | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Operational conditions | |||||
| Operating relative humidity (H-H) | 0 - 95% | 5 - 95% | 5 - 90% | 0 - 95% | 0 - 95% |
| Operating temperature (T-T) | 0 - 50 °C | 5 - 35 °C | 0 - 70 °C | 0 - 40 °C | 5 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C | -40 - 70 °C | -10 - 70 °C | -20 - 70 °C | -20 - 70 °C |
| Packaging data | |||||
| Package depth | 270 mm | 267 mm | 241 mm | 145 mm | 195 mm |
| Package height | 90 mm | 90 mm | 32 mm | 90 mm | 37 mm |
| Package weight | 1.3 kg | 1.5 kg | 210 g | 1.4 kg | 270 g |
| Package width | 155 mm | 157 mm | 124 mm | 235 mm | 139 mm |
| Sustainability | |||||
| Sustainability compliance | — | Yes | Yes | Yes | — |
