StarTech.com USB-C Triple-Monitor Multiport Adapter, Dual 4K 60Hz + 4k 30Hz HDMI & DisplayPort, 3-Port USB 10Gbps Hub, 100W Power Delivery Pass-Through, GbE, 2ft Cable, Mini Dock - Travel Laptop Docking Station (117B-USBC-MULTIPORT) - Docking station - USB-C 3.2 Gen 2 / Thunderbolt 3 / Thunderbolt 4 - 2 x HDMI, 2 x DP - 1GbE
Manuf P/N: 117B-USBC-MULTIPORT
APAXON#: 9774161
EAN: 0065030896078
StarTech.com USB-C Triple-Monitor Multiport Adapter, Dual 4K 60Hz + 4k 30Hz HDMI & DisplayPort, 3-Port USB 10Gbps Hub, 100W Power Delivery Pass-Through, GbE, 2ft Cable, Mini Dock - Travel Laptop Docking Station (117B-USBC-MULTIPORT) - Docking station - USB-C 3.2 Gen 2 / Thunderbolt 3 / Thunderbolt 4 - 2 x HDMI, 2 x DP - 1GbE
- Wired
- Host interface: USB 3.2 Gen 2 (3.1 Gen 2) Type-C
- USB Power Delivery (USB PD)
- Ethernet LAN 10,100,1000 Mbit/s Wake-on-LAN ready
- Full duplex
Stock7
Price £136.27
Quantity
|
Similar Products
Product Summary
StarTech.com USB-C Triple Monitor Multiport Adapter, Dual 4K 60Hz + 4K 30Hz HDMI & DisplayPort, 3-Port USB 10Gbps Hub, 100W PD Pass-Through, GbE, Travel Dock, Windows & ChromeOS
Extended Specification
Ports & interfaces
Connectivity technology
Wired
Host interface
USB 3.2 Gen 2 (3.1 Gen 2) Type-C
USB 2.0 ports quantity
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
0
HDMI ports quantity
2
Microphone in
No
Headphone outputs
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
3
USB Power Delivery (USB PD)
Yes
USB Power Delivery revision
3.0
USB Power Delivery up to
100 W
HDMI version
2.0b
DisplayPorts quantity
2
DisplayPort version
1.4
Network
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Ethernet LAN data rates
10,100,1000 Mbit/s
Wake-on-LAN ready
Yes
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Full duplex
Yes
Performance
Product colour
Grey
Card reader integrated
No
Data transfer rate
10 Gbit/s
HD type
4K Ultra HD
Maximum digital resolution
3840 x 2160 pixels
Number of displays supported
3
Maximum refresh rate
60 Hz
LED indicators
Yes
UASP support
Yes
Housing material
Plastic
Power
Power source type
USB
Power consumption (typical)
15 W
USB cable length
0.6 m
Software
Windows operating systems supported
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Other operating systems supported
ChromeOS
Operational conditions
Operating temperature (T-T)
0 - 70 °C
Storage temperature (T-T)
-10 - 70 °C
Operating relative humidity (H-H)
5 - 90%
Weight & dimensions
Width
56 mm
Depth
122 mm
Height
18 mm
Weight
113 g
Packaging data
Package width
124 mm
Package depth
241 mm
Package height
32 mm
Package weight
210 g
Packaging content
Quick start guide
Yes
Technical details
Compliance certificates
CE, Federal Communications Commission (FCC), RoHS
Logistics data
Products per master (outer) case
24 pc(s)
Master (outer) case width
290 mm
Master (outer) case length
530 mm
Master (outer) case height
235 mm
Other features
Chipset
Parade - PS8469, Synaptics - VMM5322, VIA - VL822, VIA - VL103, Realtek - RTL8153
Sustainability
Sustainability compliance
Yes
