StarTech.com 4-Port DisplayPort 1.4 KVM Switch, 8K 60Hz / 4K 144Hz, 2x USB 3.0 Ports, 4x USB 2.0 Ports, Hotkey Switching, TAA Compliant (D86A2-4-PORT-8K-KVM) - KVM / audio / USB switch - 4 x KVM / audio / USB - 1 local user - desktop - TAA Compliant
- Black
- Number of computers controlled: 4
- Keyboard port type: USB Mouse port type: USB Video port type: DisplayPort
- 8K Ultra HD 7680 x 4320 pixels
- Housing material: Steel
- Hot keys
- DC 36 W
Similar Products
Overview
StarTech.com 4-Port DisplayPort KVM Switch, 8K 60Hz / 4K 144Hz, Single Display, DP 1.4, 2x USB 3.0 Ports, 4x USB 2.0 HID Ports, Push-Button & Hotkey Switching, TAA Compliant - OS Independent, Metal Housing
Specifications
Ports & interfaces
- Number of computers controlled
- 4
- Keyboard port type
- USB
- Mouse port type
- USB
- Video port type
- DisplayPort
- Console ports
- 3.5mm headphone, DisplayPort, USB A
- DisplayPorts quantity
- 4
- DisplayPort version
- 1.4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity
- 4
- Console DisplayPorts ports quantity
- 1
- USB 2.0 Type-A hub ports quantity
- 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity
- 2
- Audio connections
- Yes
- Headphone outputs
- 4
- DC-in jack
- Yes
Performance
- HD type
- 8K Ultra HD
- Maximum resolution
- 7680 x 4320 pixels
- Data transfer rate (max)
- 5000 Gbit/s
- Scan interval
- 3,8,15,30 s
- High Dynamic Range (HDR) supported
- Yes
- HDCP
- Yes
- Daisy chain
- No
- Chipset
- GL-3523
- HDCP version
- 1.4/2.2
Design
- Rack mounting
- No
- Product colour
- Black
- Housing material
- Steel
- LED indicators
- Yes
- Push button
- Yes
- Hot keys
- Yes
- Mean time between failures (MTBF)
- 130000 h
Display
- Built-in display
- No
Power
- Power source
- DC
- Input voltage
- 100 - 240 V
- Input current
- 1 A
- Output voltage
- 12 V
- Output current
- 3 A
- Power consumption (typical)
- 36 W
- Power plug type
- Type M
- Compatible power plug types
- EU, JP, UK, US
Sustainability
- Compliance certificates
- CE, RoHS, Trade Agreements Act (TAA)
- Sustainability compliance
- Yes
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -20 - 60 °C
- Operating relative humidity (H-H)
- 0 - 85%
Weight & dimensions
- Width
- 130 mm
- Depth
- 220 mm
- Height
- 44 mm
- Weight
- 1 kg
Packaging data
- Package width
- 409 mm
- Package depth
- 212 mm
- Package height
- 87 mm
- Package weight
- 1.6 kg
Packaging content
- Quick installation guide
- Yes
- Rubber feet
- Yes
Logistics data
- Master (outer) case width
- 545 mm
- Master (outer) case length
- 427 mm
- Master (outer) case height
- 245 mm
- Products per master (outer) case
- 60 pc(s)
Other features
- IP control
- No
