StarTech.com USB-C Triple Monitor Docking Station - HDMI/DP Triple 4k USB-C Dock - 5x USB Hub - GbE - 100W PD - Universal Multi Monitor Docking Station - Thunderbolt 3/4 Compatible (116U-USBC-DOCK) - Docking station - USB-C 3.2 Gen 2 - 2 x HDMI, 2 x DP - 1GbE - 100 Watt
- Wired
- Host interface: USB 3.2 Gen 2 (3.1 Gen 2) Type-C
- USB Power Delivery (USB PD)
- Ethernet LAN 10,100,1000 Mbit/s 10BASE-T, 100BASE-TX, 1000BASE-T Wake-on-LAN ready
- Cable lock slot
Similar Products
Overview
StarTech.com USB-C Triple Monitor Docking Station - HDMI/DP Triple 4k USB-C Dock - 5x USB Hub - GbE - 100W PD - Universal Multi Monitor Docking Station - Thunderbolt 3/4 Compatible
Specifications
Ports & interfaces
- Connectivity technology
- Wired
- Host interface
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C
- USB 2.0 ports quantity
- 0
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 2
- HDMI ports quantity
- 3
- Headphone outputs
- 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
- 1
- USB Power Delivery (USB PD)
- Yes
- USB Power Delivery revision
- 3.0
- USB Power Delivery up to
- 100 W
- HDMI version
- 2.0
- DisplayPorts quantity
- 2
- DisplayPort version
- 1.4
- Combo headphone/mic port
- Yes
- Headphone connectivity
- 3.5 mm
- DC-in jack
- Yes
- USB Type-C DisplayPort Alternate Mode
- Yes
Network
- Ethernet LAN
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- Ethernet LAN data rates
- 10,100,1000 Mbit/s
- Copper ethernet cabling technology
- 10BASE-T, 100BASE-TX, 1000BASE-T
- Wake-on-LAN ready
- Yes
- Networking standards
- IEEE 802.3ab
Performance
- Product colour
- Grey
- Card reader integrated
- No
- Data transfer rate
- 10 Gbit/s
- HD type
- 4K Ultra HD
- Maximum digital resolution
- 4096 x 2160 pixels
- Maximum refresh rate
- 60 Hz
- Cable lock slot
- Yes
- Cable lock slot type
- Kensington
- LED indicators
- Power
- Housing material
- Plastic
Power
- Power source type
- DC
- AC input voltage
- 100 - 240 V
- Input current
- 2.5 A
- Output voltage
- 24 V
- Output current
- 5.41 A
- Power consumption (typical)
- 15 W
- Power plug type
- Type M
Software
- Windows operating systems supported
- Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
- Mac operating systems supported
- Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
- Linux operating systems supported
- Yes
- Mobile operating systems supported
- Android
- Other operating systems supported
- ChromeOS
Operational conditions
- Operating temperature (T-T)
- 0 - 70 °C
- Storage temperature (T-T)
- -10 - 55 °C
- Operating relative humidity (H-H)
- 0 - 85%
Weight & dimensions
- Width
- 85 mm
- Depth
- 190 mm
- Height
- 30 mm
- Weight
- 350 g
Packaging data
- Package width
- 205 mm
- Package depth
- 250 mm
- Package height
- 50 mm
- Package weight
- 1.1 kg
Packaging content
- Cables included
- USB Type-C to USB Type-C
- AC adapter included
- Yes
- Quick start guide
- Yes
Technical details
- Compliance certificates
- CE
Logistics data
- Products per master (outer) case
- 10 pc(s)
- Master (outer) case width
- 280 mm
- Master (outer) case length
- 430 mm
- Master (outer) case height
- 290 mm
Other features
- Chipset
- DisplayLink - DL-6950-N, VIA - VL817C0, Parade - PS176C0
Sustainability
- Sustainability compliance
- Yes
