StarTech.com USB-C Triple Monitor Docking Station - HDMI/DP Triple 4k USB-C Dock - 5x USB Hub - GbE - 100W PD - Universal Multi Monitor Docking Station - Thunderbolt 3/4 Compatible (116U-USBC-DOCK) - Docking station - USB-C 3.2 Gen 2 - 2 x HDMI, 2 x DP - 1GbE - 100 Watt
Manuf P/N: 116U-USBC-DOCK
APAXON#: 9749348
EAN: 0065030900096
StarTech.com USB-C Triple Monitor Docking Station - HDMI/DP Triple 4k USB-C Dock - 5x USB Hub - GbE - 100W PD - Universal Multi Monitor Docking Station - Thunderbolt 3/4 Compatible (116U-USBC-DOCK) - Docking station - USB-C 3.2 Gen 2 - 2 x HDMI, 2 x DP - 1GbE - 100 Watt
- Wired
- Host interface: USB 3.2 Gen 2 (3.1 Gen 2) Type-C
- USB Power Delivery (USB PD)
- Ethernet LAN 10,100,1000 Mbit/s 10BASE-T, 100BASE-TX, 1000BASE-T Wake-on-LAN ready
- Cable lock slot
Stock3
Price £ 153.63
Price inc. VAT
£ 184.36
Quantity
|
Similar Products
Product Summary
StarTech.com USB-C Triple Monitor Docking Station - HDMI/DP Triple 4k USB-C Dock - 5x USB Hub - GbE - 100W PD - Universal Multi Monitor Docking Station - Thunderbolt 3/4 Compatible
Extended Specification
Ports & interfaces
Connectivity technology
Wired
Host interface
USB 3.2 Gen 2 (3.1 Gen 2) Type-C
USB 2.0 ports quantity
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
HDMI ports quantity
3
Headphone outputs
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
USB Power Delivery (USB PD)
Yes
USB Power Delivery revision
3.0
USB Power Delivery up to
100 W
HDMI version
2.0
DisplayPorts quantity
2
DisplayPort version
1.4
Combo headphone/mic port
Yes
Headphone connectivity
3.5 mm
DC-in jack
Yes
USB Type-C DisplayPort Alternate Mode
Yes
Network
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Ethernet LAN data rates
10,100,1000 Mbit/s
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
Wake-on-LAN ready
Yes
Networking standards
IEEE 802.3ab
Performance
Product colour
Grey
Card reader integrated
No
Data transfer rate
10 Gbit/s
HD type
4K Ultra HD
Maximum digital resolution
4096 x 2160 pixels
Maximum refresh rate
60 Hz
Cable lock slot
Yes
Cable lock slot type
Kensington
LED indicators
Power
Housing material
Plastic
Power
Power source type
DC
AC input voltage
100 - 240 V
Input current
2.5 A
Output voltage
24 V
Output current
5.41 A
Power consumption (typical)
15 W
Power plug type
Type M
Software
Windows operating systems supported
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Mac operating systems supported
Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Linux operating systems supported
Yes
Mobile operating systems supported
Android
Other operating systems supported
ChromeOS
Operational conditions
Operating temperature (T-T)
0 - 70 °C
Storage temperature (T-T)
-10 - 55 °C
Operating relative humidity (H-H)
0 - 85%
Weight & dimensions
Width
85 mm
Depth
190 mm
Height
30 mm
Weight
350 g
Packaging data
Package width
205 mm
Package depth
250 mm
Package height
50 mm
Package weight
1.1 kg
Packaging content
Cables included
USB Type-C to USB Type-C
AC adapter included
Yes
Quick start guide
Yes
Technical details
Compliance certificates
CE
Logistics data
Products per master (outer) case
10 pc(s)
Master (outer) case width
280 mm
Master (outer) case length
430 mm
Master (outer) case height
290 mm
Other features
Chipset
DisplayLink - DL-6950-N, VIA - VL817C0, Parade - PS176C0
Sustainability
Sustainability compliance
Yes
