D-Link DGS 1010MP
Switch
unmanaged
8 x 10/100/1000 (PoE+) + 1 x 10/100/1000 (uplink) + 1 x 1000Base-X SFP (uplink)
desktop, rack-mountable
PoE+ (125 W)
Weight: 2.66 KG
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity: 8
- Cat3, Cat4, Cat5, Cat5e 10BASE-T, 100BASE-TX, 1000BASE-T
- MAC address table: 4000 entries Switching capacity: 20 Gbit/s
- 1U Rack mounting
- Power over Ethernet (PoE)
Similar Products
Overview
The D-Link DGS-1010MP Gigabit PoE switch is an ideal solution for small offices and enterprise environments looking to expand the network with a set of PoE devices such as wireless access points, IP cameras, and IP phones. Built with small business and enterprise users in mind, the DGS-1010MP is a high-speed, flexible switch that features a fanless, quiet design so it can be conveniently placed anywhere in a working environment.
Specifications
Data transmission
- MAC address table
- 4000 entries entries
- Switching capacity
- 20 Gbit/s Gbit/s
- Packet forwarding rate (1 Gbps)
- 1488000 pps pps
- Packet forwarding rate (100 Mbps)
- 148800 pps pps
- Packet forwarding rate (10 Mbps)
- 14880 pps pps
- MAC address table
- 4000 entries
- Switching capacity
- 20 Gbit/s
- Store-and-forward
- Yes
- Packet forwarding rate (1 Gbps)
- 1488000 pps
- Packet forwarding rate (100 Mbps)
- 148800 pps
- Packet forwarding rate (10 Mbps)
- 14880 pps
Performance
- Maximum cable length
- 100 m m
- Buffer size
- 192 KB KB
- Maximum cable length
- 100 m
- Buffer size
- 192 KB
- Plug and Play
- Yes
Power
- Voltage Required
- AC 120/230 V (50/60 Hz) V
- AC input frequency
- 50 - 60 Hz Hz
- Power consumption (max)
- 133.8 W W
- AC input frequency
- 50 - 60 Hz
- Power consumption (max)
- 133.8 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE) power per port
- 30 W W
- Total Power over Ethernet (PoE) budget
- 125 W W
- Power over Ethernet (PoE)
- Yes
- Power over Ethernet (PoE) ports quantity
- 8
- Power over Ethernet (PoE) power per port
- 30 W
- Total Power over Ethernet (PoE) budget
- 125 W
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C °C
- Storage temperature (T-T)
- -10 - 70 °C °C
- Operating relative humidity (H-H)
- 0 - 95% %
- Storage relative humidity (H-H)
- 0 - 95% %
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -10 - 70 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Storage relative humidity (H-H)
- 0 - 95%
Weight & dimensions
- Width
- 280 mm mm
- Depth
- 180 mm mm
- Height
- 44 mm mm
- Width
- 280 mm
- Depth
- 180 mm
- Height
- 44 mm
Management features
- Switch type
- Unmanaged
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity
- 8
- Basic switching RJ-45 Ethernet ports type
- Gigabit Ethernet (10/100/1000)
- Installed SFP modules quantity
- 0
- Installed SFP+ modules quantity
- 0
- SFP module slots quantity
- 1
- Power connector
- AC-in jack
Network
- Networking standards
- IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
- 10G support
- No
- Copper ethernet cabling technology
- 10BASE-T, 100BASE-TX, 1000BASE-T
- Cable types supported
- Cat3, Cat4, Cat5, Cat5e
- Full duplex
- Yes
- Flow control support
- Yes
- Auto MDI/MDI-X
- Yes
- Auto-negotiation
- Yes
Design
- Rack mounting
- Yes
- Form factor
- 1U
- Product colour
- Black
- Housing material
- Metal
- LED indicators
- Activity, Link, PoE, Power, Status
- Safety
- cUL, CB, CCC, LVD
- Electromagnetic compatibility
- CE A, FCC A, VCCI A, CCC A, FCC A
Certificates
- Certification
- RoHS
General
- Subtype
- Gigabit Ethernet
- Power Over Ethernet (PoE)
- PoE+
- Device Type
- Switch - 10 ports - unmanaged
- Enclosure Type
- Desktop, rack-mountable 1U
- Performance
- Switching capacity: 20 Gbps
- Ports
- 8 x 10/100/1000 (PoE+) + 1 x 10/100/1000 (uplink) + 1 x 1000Base-X SFP (uplink)
- Capacity
- Packet buffer size: 192
- Features
- Fanless, flow control, EEE, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, half duplex mode, full duplex mode, security slot (Kensington security lock compatible)
- Status Indicators
- Link/activity/speed, power, status, PoE
