D-Link 5-port 10/100 Desktop Switch
Manuf P/N: DES-1005D/B
APAXON#: 2421074
EAN: 790069219887
D-Link 5-port 10/100 Desktop Switch
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity: 5
- MAC address table: 2000 entries Switching capacity: 1 Gbit/s
- AC Power supply included
- Cat3, Cat4, Cat5, Cat5e 100Base-TX, 10Base-T
Stock0
Price £11.73
Quantity
|
Similar Products
Product Summary
D-Link DES-1005D 5 Port Fast Ethernet Unmanaged Desktop Switch
Extended Specification
Group 763
Basic switching RJ-45 Ethernet ports quantity
5
Basic switching RJ-45 Ethernet ports type
Fast Ethernet (10/100)
Installed SFP modules quantity
0
Installed SFP+ modules quantity
0
Power connector
DC-in jack
Group 1141
Networking standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3x
10G support
No
Copper ethernet cabling technology
100Base-TX, 10Base-T
Cable types supported
Cat3, Cat4, Cat5, Cat5e
Full duplex
Yes
Flow control support
Yes
Auto MDI/MDI-X
Yes
Ethernet LAN data rates
10,100 Mbit/s
Auto-negotiation
Yes
MAC address auto-learning supported
Yes
Group 2484
MAC address table
2000 entries
Switching capacity
1 Gbit/s
Supported data transfer rates
10/20/100/200 Mb/s
Forwarding rate
0.1488 Mpps
Store-and-forward
Yes
Maximum data transfer rate
0.2 Gbit/s
Packet buffer memory
0.046875 MB
Group 2944
Switch type
Unmanaged
Group 2987
Switching protocols
CSMA/CD
Data link protocols
Ethernet, Fast Ethernet
Group 10881
Rack mounting
No
Stackable
No
Product colour
Black
Housing material
Plastic
LED indicators
Activity, Link, Power
Group 10882
Plug and Play
Yes
Fanless
Yes
Group 1142
Power source
AC
Power supply included
Yes
Input current
1.2 A
Input voltage
5 V
Power consumption (typical)
2.5 W
Power consumption (max)
3.8 W
Group 9999
Power over Ethernet (PoE)
No
Group 8343
Packet transfer speed
14880 - 148800 p/s
Power LED
Yes
Group 1143
Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-10 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
5 - 90%
Heat dissipation
8.528 BTU/h
Group 1144
Width
125.3 mm
Depth
83.4 mm
Height
29.1 mm
Group 49104
Cables included
AC
User guide
Yes
Manual
Yes
Group 2483
Package width
65 mm
Package depth
105 mm
Package height
98 mm
Package weight
170 g
Group 41469
Certification
FCC Class B, ICES-003 Class B, CE Class B, C-Tick Class B, VCCI Class B, cUL, CB
Group 24990
Harmonized System (HS) code
85176990
