TP-Link Omada SG6654XHP V1 - Switch - L3 - Managed - 48 x 10/100/1000 (PoE+) + 6 x 10Gb Ethernet SFP+ - front to back airflow - rack-mountable - PoE+ (1440 W)

Name: TP-Link Omada SG6654XHP V1 - Switch - L3 - Managed - 48 x 10/100/1000 (PoE+) + 6 x 10Gb Ethernet SFP+ - front to back airflow - rack-mountable - PoE+ (1440 W)
Brand: TP-Link
SKU: SG6654XHP
Price: 3107.41 GBP
Availability: OutOfStock

Manuf P/N: SG6654XHP

APAXON#: 9852246

EAN: 4895252501421

Managed L3 Web-based management
Quality of Service (QoS) support Configuring Location Settings (CLI)
Basic switching RJ-45 Ethernet ports quantity: 48 Console port: RJ-45/USB Type-C
MAC address table: 32000 entries Switching capacity: 216 Gbit/s
Access Control List (ACL)
1U Rack mounting Stackable
AC Power supply included Power over Ethernet (PoE)

Stock0

Price £3,107.41

Quantity

Notify me when available.

Product Summary

TP-Link Omada 48-Port Gigabit Stackable L3 Managed PoE+ Switch with 6 10G Slots

Extended Specification

Group 2944

Switch type

Managed

Switch layer

Quality of Service (QoS) support

Yes

Web-based management

Yes

Cloud-managed

Yes

ARP inspection

Yes

Configuring Location Settings (CLI)

Yes

System event log

Yes

Group 763

Basic switching RJ-45 Ethernet ports quantity

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

SFP+ module slots quantity

Console port

RJ-45/USB Type-C

USB 2.0 ports quantity

Group 1141

Networking standards

IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x

10G support

Port mirroring

Yes

IP routing

Yes

Flow control support

Yes

Broadcast storm control

Yes

Rate limiting

Yes

Spanning tree protocol

Yes

Ethernet LAN data rates

10,100,1000 Mbit/s

VLAN support

Yes

Virtual LAN features

MAC address-based VLAN, Multicast VLAN, Private VLAN, Voice VLAN

Number of VLANs

4000

Group 2484

MAC address table

32000 entries

Switching capacity

216 Gbit/s

Forwarding rate

160.7 Mpps

Static route

Yes

Jumbo frames support

Yes

Jumbo frames

9000

Packet buffer memory

3 MB

Group 2482

DHCP features

DHCP relay, DHCP snooping, DHCPv6 snooping

Access Control List (ACL)

Yes

IGMP snooping

Yes

IGMP entries

2048

SSH/SSL support

Yes

Loop protection

Yes

Authentication

Auto VLAN, MAC-based authentication, Port-based authentication

Authentication type

RADIUS

Group 27921

Multicast support

Yes

Group 10881

Rack mounting

Yes

Stackable

Yes

Form factor

Product colour

Black

LED indicators

Yes

Number of fans

4 fan(s)

Group 1142

Power source

Power supply included

Yes

AC input voltage

100 - 240 V

AC input frequency

50/60 Hz

Power consumption (max)

1767.7 W

Group 9999

Power over Ethernet (PoE)

Yes

Power over Ethernet plus (PoE+) ports quantity

Power over Ethernet (PoE) power per port

30 W

Total Power over Ethernet (PoE) budget

1440 W

Group 1143

Operating temperature (T-T)

-5 - 40 °C

Storage temperature (T-T)

-40 - 70 °C

Operating relative humidity (H-H)

10 - 90%

Storage relative humidity (H-H)

5 - 90%

Heat dissipation

6027.86 BTU/h

Group 1144

Width

440 mm

Depth

420 mm

Height

44 mm

Group 49104

Cables included

AC, LAN (RJ-45)

Manual

Yes

TP-Link Omada SG6654XHP V1 - Switch - L3 - Managed - 48 x 10/100/1000 (PoE+) + 6 x 10Gb Ethernet SFP+ - front to back airflow - rack-mountable - PoE+ (1440 W)
