Compare D-Link Hubs & Switches
Comparing 5 products side-by-side — specifications, pricing and stock. Showing D-Link products in the Hubs & Switches category.
| Specification | |||||
|---|---|---|---|---|---|
| General | |||||
| Authentication Method | RADIUS, Secure Shell v.2 (SSH2), internal user database, Extensible Authentication Protocol (EAP) | RADIUS, Secure Shell v.2 (SSH2), internal user database, Extensible Authentication Protocol (EAP) | — | RADIUS, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP) | — |
| Capacity | IGMP groups: 256, QoS hardware queues per port: 8, ACL rules: 256, ARP entries: 256, VLAN groups: 4094, IPv4 routing table entries: 32, IPv6 routing table entries: 16 | IGMP groups: 256 QoS hardware queues per port: 8 ACL rules: 768 ARP entries: 64 | — | — | VLAN groups: 128 VLAN IDs: 4094 IGMP groups: 128 |
| Device Type | — | Switch - 52 ports - Managed | — | — | Switch - 24 ports - smart |
| Enclosure Type | — | Desktop, rack-mountable 1U | — | Rack-mountable 1U | Desktop, rack-mountable 1U |
| Encryption Algorithm | MD5, SSL, TLS, SSL 3.0, SSL 2.0, PEAP, TTLS | MD5, SSL, TLS, SSL 3.0, SSL 2.0, PEAP, TTLS | — | SSL, TLS, SSL 3.0, SSL 2.0, PEAP, TTLS | SSL |
| Features | Flow control, full duplex capability, auto-negotiation, BOOTP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, WRR queuing, store and forward, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, STP support, RSTP support, DHCP snooping, ACL support, QoS, MLD snooping, DAI, Safeguard Engine, Cable Diagnostics Function, bandwidth control, D-Link Green Technology, Port Security, IP-MAC binding, SNMP trap, DHCP client, SPQ, Multicast filtering function, CoS, TFTP client, security lock slot (cable lock sold separately), 802.1x authentication, ToS, DSCP support, 1.5MB packet buffer | Flow control, full duplex capability, auto-negotiation, BOOTP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, WRR queuing, store and forward, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, STP support, RSTP support, DHCP snooping, ACL support, QoS, MLD snooping, DAI, Safeguard Engine, Cable Diagnostics Function, bandwidth control, D-Link Green Technology, Port Security, IP-MAC binding, SNMP trap, DHCP client, SPQ, Multicast filtering function, CoS, TFTP client, security lock slot (cable lock sold separately), 802.1x authentication, ToS, DSCP support, 3MB packet buffer | — | Flow control, auto-negotiation, ARP support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DoS attack prevention, port mirroring, store and forward, Broadcast Storm Control, half duplex mode, full duplex mode, Multicast Storm Control, Unicast Storm Control, sFlow, STP support, RSTP support, MSTP support, DHCP snooping, ACL support, QoS, MLD snooping, DAI, reset button, LLDP support, DHCP relay, LACP, Port Security, SNMP trap, DHCP client, GVRP, dual firmware images, SPQ, Multicast filtering function, TFTP client, ERPS, cable test, system log, IP source guard, DRR, BPDU, ICMP, NTP, AAA, WAC, LLDP-MED, WRR, HOL Blocking Prevention, loopback detection | Flow control, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DoS attack prevention, port mirroring, Broadcast Storm Control, full duplex mode, Multicast Storm Control, Unicast Storm Control, STP support, RSTP support, QoS, Cable Diagnostics Function, bandwidth control, fanless, LLDP support, Port Security, DHCP client, 512KB packet buffer, tagged VLAN, DSCP support, IGMP querier, Voice VLAN, VLAN management, VLAN group, EEE, WRR, HOL Blocking Prevention, loopback detection, port-based VLAN, port-based QoS, Unknown Storm Control, DNA support, Asymmetric VLAN |
| Performance | Switching capacity: 56 Gbps, Forwarding performance (64-byte packet size): 41.7 Mpps | Switching capacity: 104 Gbps Forwarding performance (64-byte packet size): 77.4 Mpps | — | Switching capacity: 176 Gbps Forwarding performance: 130.95 Mpps | Switching capacity: 48 Gbps Forwarding performance: 35.71 Mpps |
| Ports | — | 8 x 10/100/1000 (PoE+) + 40 x 10/100/1000 (PoE) + 4 x SFP | — | 48 x 10/100/1000 (PoE) + 4 x 10 Gigabit SFP+ | 24 x 10/100/1000 (12 PoE) |
| Power Over Ethernet (PoE) | — | — | — | — | PoE |
| RAM | — | — | — | 2 GB DDR3 SDRAM | — |
| Remote Management Protocol | — | SNMP 1, RMON 1, Telnet, SNMP 3, SNMP 2c, HTTP, CLI | — | — | SNMP 2, ICMP |
| Routing Protocol | — | — | — | — | IGMPv2, IGMP, IGMPv3 |
| Status Indicators | — | Port transmission speed, power, PoE, link/activity, fan | — | Power, error, fan, link/activity/speed, stack | Power, status, PoE, link/activity/speed |
| Subtype | Gigabit Ethernet | Gigabit Ethernet | — | — | Gigabit Ethernet |
| Power | |||||
| AC input frequency | 50 - 60 Hz | 50/60 Hz | 50/60 Hz | 50 - 60 Hz | — |
| AC input voltage | 100 - 240 V | 100 - 240 V | 100 - 240 V | — | — |
| Power consumption (max) | — | 478.9 W | 236.9 W | 467.3 W | 19.5 W |
| Power consumption (typical) | 27.49 W | — | — | — | — |
| Power source | — | AC | AC | — | — |
| Power supply included | — | Yes | Yes | — | — |
| Voltage Required | AC 120/230 V (50/60 Hz) | AC 120/230 V (50/60 Hz) | — | AC 120/230 V (50/60 Hz) | AC 120/230 V (50/60 Hz) |
| Network | |||||
| 10G support | — | — | — | — | No |
| Auto MDI/MDI-X | — | Yes | Yes | Yes | Yes |
| Auto-negotiation | — | Yes | Yes | — | Yes |
| Broadcast storm control | — | Yes | Yes | Yes | Yes |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 100BASE-T, 1000BASE-T | 10BASE-T, 100BASE-TX, 1000BASE-T | 10BASE-T, 100BASE-TX, 1000BASE-T | — | 10BASE-T, 10BASE-TX, 1000BASE-T |
| Flow control support | Yes | Yes | Yes | — | Yes |
| Full duplex | Yes | Yes | Yes | — | Yes |
| Head-of-line (HOL) blocking | — | Yes | Yes | — | Yes |
| IP routing | Yes | — | — | — | — |
| Link aggregation | — | Yes | Yes | Yes | Yes |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z | IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Number of VLANs | 4094 | 256 | 256 | 4094 | 128 |
| Port mirroring | Yes | Yes | Yes | — | Yes |
| Rate limiting | — | — | — | — | Yes |
| Spanning tree protocol | — | Yes | Yes | Yes | Yes |
| Virtual LAN features | Voice VLAN, Tagged VLAN, MAC address-based VLAN, Port-based VLAN | — | — | — | Port-based VLAN, Voice VLAN |
| VLAN support | Yes | Yes | Yes | — | Yes |
| Security | |||||
| Access Control List (ACL) | Yes | Yes | Yes | Yes | — |
| Access Control List (ACL) rules | 256 | — | — | — | — |
| Authentication | Guest VLAN, MAC-based authentication, Port-based authentication | — | — | — | — |
| BPDU filtering/protection | Yes | — | — | — | — |
| DHCP features | DHCP client | DHCP server, DHCP client | DHCP server, DHCP client | — | DHCP client |
| IGMP snooping | — | Yes | Yes | — | Yes |
| IP-MAC-Port binding | Yes | — | — | Yes | — |
| Loop protection | Yes | Yes | Yes | Yes | — |
| MAC address filtering | — | Yes | Yes | — | — |
| Queue scheduling algorithms | — | — | — | Weighted Round Robin (WRR) | SPQ, Weighted Round Robin (WRR) |
| Security algorithms | 802.1x RADIUS, SNMP, SSH | — | — | EAP, LEAP, PEAP, SSH, TTLS | SNMP, SSL/TLS |
| SSH/SSL support | Yes | — | — | — | — |
| Management features | |||||
| ARP inspection | — | Yes | Yes | — | — |
| Cloud-managed | — | — | — | No | — |
| Configuring Location Settings (CLI) | — | Yes | Yes | Yes | — |
| MIB support | RFC1213MIB II, RFC1493, RFC1907, RFC1757, 2819, RFC2021, RFC1398, 1643, 1650, 2358, 2665, RFC2674, 4363, RFC 2233, 2863, RFC 2618, RFC 2620, RFC 2925 | Y | Y | RFC2893, RFC4213, RFC4291, RFC2464, RFC2462, RFC4862, RFC2461, RFC4861, RFC2573, RFC1321, RFC2284, RFC2865, RFC2716, RFC3580, RFC826, RFC2463, RFC4443, RFC792, RFC793, RFC768, RFC791, RFC2389, RFC4113, RFC4022, RFC2618, RFC2674, RFC1398, RFC1643, RFC1650, RFC2358, RFC2665, RFC2021, RFC271, RFC1757, RFC2819, RFC1442, RFC1901, RFC1902, RFC1903, RFC1904, RFC1905, RFC1906, RFC1907, RFC1908, RFC2578, RFC3418, RFC2573, RFC2575, RFC2576, RFC1212, RFC1213, RFC1215, RFC1493, RFC1157, RFC2620, | — |
| Quality of Service (QoS) support | — | Yes | Yes | Yes | Yes |
| Switch layer | — | L2 | L2 | L3 | L2 |
| Switch type | Managed | Managed | Managed | Managed | Managed |
| System event log | Yes | Yes | Yes | Yes | Yes |
| Web-based management | — | Yes | Yes | Yes | Yes |
| Ports & interfaces | |||||
| Basic switching RJ-45 Ethernet ports quantity | 24 | 48 | 24 | 48 | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) | Gigabit Ethernet (10/100/1000) | Gigabit Ethernet (10/100/1000) | — | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity | — | 4 | 4 | — | — |
| Console port | RJ-45 | — | — | RJ-45 | — |
| Fiber optic connector | SFP | — | — | — | — |
| Installed SFP modules quantity | 0 | 0 | 0 | 0 | 0 |
| Installed SFP+ modules quantity | — | 0 | 0 | 0 | 0 |
| Power connector | — | AC-in jack | AC-in jack | — | — |
| SFP module slots quantity | 4 | — | — | — | — |
| SFP+ module slots quantity | — | — | — | 4 | — |
| Performance | |||||
| Built-in processor | Yes | — | — | — | Yes |
| Fanless | — | — | — | — | Yes |
| Flash memory | 32 MB | 32 MB | 32 MB | — | 16 MB |
| Internal memory | 128 MB | 256 MB | 256 MB | 2048 MB | — |
| Mean time between failures (MTBF) | 294101 h | 236667 h | 469262 h | 309053.1 h | 255003 h |
| Memory type | DDR3-SDRAM | DDR3-SDRAM | DDR3-SDRAM | DDR3-SDRAM | DRAM |
| Noise level | 52.4 dB | 52.4 dB | 51.7 dB | 51.2 dB | 0 dB |
| Processor frequency | — | — | — | — | 125 MHz |
| Certificates | |||||
| Certification | IEC61000-4-5, RoHS | — | — | — | EMI FCC A, CE A, VCCI A, C-Tick, BSMI, CCC cUL, CE LVD, CB, BSMI, CCC |
| Weight & dimensions | |||||
| Depth | 210 mm | 430 mm | 140 mm | 430 mm | 230 mm |
| Height | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Weight | — | 6.26 kg | 2.15 kg | 3.85 kg | 2.2 kg |
| Width | 440 mm | 440 mm | 440 mm | 440 mm | 280 mm |
| Design | |||||
| Electromagnetic compatibility | FCC A, CE A, VCCI, C-Tick, BSMI, CCC | — | — | CE A, VCCI A, FCC A, IC, BSMI | — |
| Form factor | 1U | 1U | 1U | — | — |
| LED indicators | Activity, Fan fail, Link, Power, Speed | Yes | Yes | Activity, Link, Power, Speed | Yes |
| Number of fans | 2 fan(s) | — | 2 fan(s) | — | — |
| Product colour | — | Black | Black | Black | Black |
| Rack mounting | Yes | Yes | Yes | — | Yes |
| Stackable | — | Yes | Yes | — | — |
| Optical fiber | |||||
| Fiber ethernet cabling technology | 1000BASE-X | — | — | — | — |
| Data transmission | |||||
| Forwarding rate | 41.7 Mpps | 77.4 Mpps | 41.7 Mpps | 130.95 Mpps | 35.71 Mpps |
| Jumbo frames | — | 10000 | 10000 | 12000 | 9216 |
| Jumbo frames support | — | Yes | Yes | — | Yes |
| MAC address table | 16000 entries | 16000 entries | 8000 entries | 32000 entries | 8000 entries |
| Number of queues | 8 | — | — | — | 4 |
| Number of static routes | — | — | — | 124 | — |
| Packet buffer memory | 1.5 MB | 12 MB | 4.1 MB | 16 MB | 4.1 MB |
| Store-and-forward | — | Yes | Yes | — | Yes |
| Switching capacity | 56 Gbit/s | 104 Gbit/s | 56 Gbit/s | 176 Gbit/s | 48 Gbit/s |
| Logistics data | |||||
| Harmonized System (HS) code | — | — | — | 85176990 | 85176990 |
| Operational conditions | |||||
| Heat dissipation | 850.58 BTU/h | 1634.01 BTU/h | 900.36 BTU/h | 1512.676 BTU/h | 107.5 BTU/h |
| Operating altitude | — | — | — | — | 0 - 2000 m |
| Operating relative humidity (H-H) | 10 - 90% | 0 - 95% | 0 - 95% | 0 - 95% | 0 - 95% |
| Operating temperature (T-T) | -5 - 50 °C | -5 - 50 °C | -5 - 50 °C | -5 - 50 °C | -5 - 50 °C |
| Storage relative humidity (H-H) | 5 - 90% | 0 - 95% | 0 - 95% | 0 - 95% | 0 - 95% |
| Storage temperature (T-T) | -40 - 70 °C | -40 - 70 °C | -40 - 70 °C | -20 - 70 °C | -40 - 70 °C |
| Technical details | |||||
| Master (outer) cases per pallet (air) | 24 pc(s) | — | — | 16 pc(s) | — |
| Master (outer) cases per pallet (sea) | 40 pc(s) | — | — | 16 pc(s) | — |
| Pallet gross length | 110 cm | — | — | 110 cm | — |
| Pallet gross weight (air) | 419.7 kg | — | — | 456.1 kg | — |
| Pallet gross weight (sea) | 682.9 kg | — | — | — | — |
| Pallet gross width | 120 cm | — | — | 120 cm | — |
| Pallet height (air) | 131.4 cm | — | — | 184.7 cm | — |
| Pallet height (sea) | 2.1 m | — | — | 184.7 cm | — |
| Products per pallet (air) | 72 pc(s) | — | — | 80 pc(s) | — |
| Products per pallet (sea) | 120 pc(s) | — | — | 80 pc(s) | — |
| Products per shipping (inner) case | 3 pc(s) | — | — | 5 pc(s) | — |
| Shipping (inner) case gross weight | 16.4 kg | — | — | 27.4 kg | — |
| Shipping (inner) case height | 39.3 cm | — | — | 42.8 cm | — |
| Shipping (inner) case length | 53.9 cm | — | — | 58.5 cm | — |
| Shipping (inner) case net weight | 15.6 kg | — | — | 22.9 kg | — |
| Shipping (inner) case width | 29.5 cm | — | — | 47.8 cm | — |
| Multicast features | |||||
| Multicast Listener Discovery (MLD) snooping | MLD v1, MLD v2 | — | — | — | — |
| Multicast support | Yes | Yes | Yes | Yes | Yes |
| Packaging data | |||||
| Package depth | 521 mm | — | — | 563 mm | — |
| Package height | 92 mm | — | — | 89 mm | — |
| Package weight | 5.18 kg | — | — | 5.17 kg | — |
| Package width | 365 mm | — | — | — | — |
| Power over Ethernet (PoE) | |||||
| Power over Ethernet (PoE) | Yes | No | Yes | Yes | Yes |
| Power over Ethernet (PoE) ports quantity | 24 | — | 24 | 48 | — |
| Power over Ethernet (PoE) power per port | — | — | — | 15.4 W | 30 W |
| Power over Ethernet plus (PoE+) ports quantity | — | — | — | — | 12 |
| Total Power over Ethernet (PoE) budget | — | — | 193 W | 370 W | 100 W |
