Compare D-Link Hubs & Switches
Comparing 5 products side-by-side — specifications, pricing and stock. Showing D-Link products in the Hubs & Switches category.
| Specification | |||||
|---|---|---|---|---|---|
| General | |||||
| Authentication Method | RADIUS, Extensible Authentication Protocol (EAP) | RADIUS, Secure Shell v.2 (SSH2), internal user database, Extensible Authentication Protocol (EAP) | — | RADIUS, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP) | RADIUS, Secure Shell v.2 (SSH2), internal user database, Extensible Authentication Protocol (EAP) |
| Capacity | IGMP groups: 384 Virtual interfaces (VLANs): 4000 ARP entries: 768 IPv4 routes (static): 64 IPv6 routes (static): 64 ACL rules: 256 Access lists: 50 | IGMP groups: 256 QoS hardware queues per port: 8 ACL rules: 768 ARP entries: 64 | — | — | IGMP groups: 256, QoS hardware queues per port: 8, ACL rules: 256, ARP entries: 256, VLAN groups: 4094, IPv4 routing table entries: 32, IPv6 routing table entries: 16 |
| Device Type | Switch - 8 ports - Managed | Switch - 52 ports - Managed | — | — | — |
| Enclosure Type | Rack-mountable 1U | Desktop, rack-mountable 1U | — | Rack-mountable 1U | — |
| Encryption Algorithm | SSL, TLS, TLS 1.0, TLS 1.1, TLS 1.2, TTLS, PEAP | MD5, SSL, TLS, SSL 3.0, SSL 2.0, PEAP, TTLS | — | SSL, TLS, SSL 3.0, SSL 2.0, PEAP, TTLS | MD5, SSL, TLS, SSL 3.0, SSL 2.0, PEAP, TTLS |
| Features | Store and forward, IGMP snooping, MLD snooping, LLDP support, STP support, RSTP support, MSTP support, flow control, port mirroring, Jumbo Frames support, loopback detection, ERPS, DSCP support, IPv6 support, WRR queuing, ARP support, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Safeguard Engine, DHCP server, Port Security, MDI/MDI-X switch, SNMP trap, BOOTP support, DHCP client, Syslog support, SNTP support, D-Link Green Technology, 6KV PoE surge protection, 2 fans, Cable Diagnostics Function, DoS attack prevention, Duplicated Address Detection, fast PoE, PD-Alive, perpetual PoE | Flow control, full duplex capability, auto-negotiation, BOOTP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, WRR queuing, store and forward, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, STP support, RSTP support, DHCP snooping, ACL support, QoS, MLD snooping, DAI, Safeguard Engine, Cable Diagnostics Function, bandwidth control, D-Link Green Technology, Port Security, IP-MAC binding, SNMP trap, DHCP client, SPQ, Multicast filtering function, CoS, TFTP client, security lock slot (cable lock sold separately), 802.1x authentication, ToS, DSCP support, 3MB packet buffer | — | Flow control, auto-negotiation, ARP support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DoS attack prevention, port mirroring, store and forward, Broadcast Storm Control, half duplex mode, full duplex mode, Multicast Storm Control, Unicast Storm Control, sFlow, STP support, RSTP support, MSTP support, DHCP snooping, ACL support, QoS, MLD snooping, DAI, reset button, LLDP support, DHCP relay, LACP, Port Security, SNMP trap, DHCP client, GVRP, dual firmware images, SPQ, Multicast filtering function, TFTP client, ERPS, cable test, system log, IP source guard, DRR, BPDU, ICMP, NTP, AAA, WAC, LLDP-MED, WRR, HOL Blocking Prevention, loopback detection | Flow control, full duplex capability, auto-negotiation, BOOTP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, WRR queuing, store and forward, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, STP support, RSTP support, DHCP snooping, ACL support, QoS, MLD snooping, DAI, Safeguard Engine, Cable Diagnostics Function, bandwidth control, D-Link Green Technology, Port Security, IP-MAC binding, SNMP trap, DHCP client, SPQ, Multicast filtering function, CoS, TFTP client, security lock slot (cable lock sold separately), 802.1x authentication, ToS, DSCP support, 1.5MB packet buffer |
| MAC Address Table Size | 32K entries | — | — | — | — |
| Performance | Switching capacity: 200 Gbps Packet forwarding rate: 148.8 Mpps | Switching capacity: 104 Gbps Forwarding performance (64-byte packet size): 77.4 Mpps | — | Switching capacity: 176 Gbps Forwarding performance: 130.95 Mpps | Switching capacity: 56 Gbps, Forwarding performance (64-byte packet size): 41.7 Mpps |
| Ports | 8 x 10GBase-T + 2 x 10 Gigabit SFP+ | 8 x 10/100/1000 (PoE+) + 40 x 10/100/1000 (PoE) + 4 x SFP | — | 48 x 10/100/1000 (PoE) + 4 x 10 Gigabit SFP+ | — |
| Power Over Ethernet (PoE) | PoE++ | — | — | — | — |
| RAM | — | — | — | 2 GB DDR3 SDRAM | — |
| Remote Management Protocol | SSH, CLI, Telnet, TFTP, SNMP 1, SNMP 2c, SNMP 3, RMON 1, RMON 2 | SNMP 1, RMON 1, Telnet, SNMP 3, SNMP 2c, HTTP, CLI | — | — | — |
| Routing Protocol | IGMP, IGMPv2, IGMPv3, MLD, MLDv2 | — | — | — | — |
| Status Indicators | Console, fan, link/activity/speed, PoE max, power | Port transmission speed, power, PoE, link/activity, fan | — | Power, error, fan, link/activity/speed, stack | — |
| Subtype | 10 Gigabit Ethernet | Gigabit Ethernet | — | — | Gigabit Ethernet |
| Power | |||||
| AC input frequency | — | 50/60 Hz | 50/60 Hz | 50 - 60 Hz | 50 - 60 Hz |
| AC input voltage | 100 - 240 V | 100 - 240 V | 100 - 240 V | — | 100 - 240 V |
| Power consumption (max) | 453.9 W | 478.9 W | 236.9 W | 467.3 W | — |
| Power consumption (typical) | — | — | — | — | 27.49 W |
| Power source | AC | AC | AC | — | — |
| Power supply included | Yes | Yes | Yes | — | — |
| Voltage Required | — | AC 120/230 V (50/60 Hz) | — | AC 120/230 V (50/60 Hz) | AC 120/230 V (50/60 Hz) |
| Network | |||||
| 10G support | Yes | — | — | — | — |
| Auto MDI/MDI-X | Yes | Yes | Yes | Yes | — |
| Auto-negotiation | — | Yes | Yes | — | — |
| Broadcast storm control | Yes | Yes | Yes | Yes | — |
| Cable types supported | Cat6, Cat6a | — | — | — | — |
| Copper ethernet cabling technology | 10GBASE-T | 10BASE-T, 100BASE-TX, 1000BASE-T | 10BASE-T, 100BASE-TX, 1000BASE-T | — | 10BASE-T, 100BASE-TX, 100BASE-T, 1000BASE-T |
| Ethernet LAN data rates | 100,1000,2500,5000,10000 Mbit/s | — | — | — | — |
| Flow control support | Yes | Yes | Yes | — | Yes |
| Full duplex | — | Yes | Yes | — | Yes |
| Head-of-line (HOL) blocking | — | Yes | Yes | — | — |
| IP routing | — | — | — | — | Yes |
| Link aggregation | Yes | Yes | Yes | Yes | — |
| Networking standards | IEEE 802.1AX, IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3bt | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Number of VLANs | 4094 | 256 | 256 | 4094 | 4094 |
| Policy-based routing | Yes | — | — | — | — |
| Port mirroring | Yes | Yes | Yes | — | Yes |
| Rate limiting | Yes | — | — | — | — |
| Spanning tree protocol | Yes | Yes | Yes | Yes | — |
| Virtual LAN features | Port-based VLAN, Voice VLAN | — | — | — | Voice VLAN, Tagged VLAN, MAC address-based VLAN, Port-based VLAN |
| VLAN support | Yes | Yes | Yes | — | Yes |
| Security | |||||
| Access Control List (ACL) | Yes | Yes | Yes | Yes | Yes |
| Access Control List (ACL) rules | — | — | — | — | 256 |
| Authentication | Auto VLAN | — | — | — | Guest VLAN, MAC-based authentication, Port-based authentication |
| Authentication type | TACACS+ | — | — | — | — |
| BPDU filtering/protection | — | — | — | — | Yes |
| DHCP features | DHCP server | DHCP server, DHCP client | DHCP server, DHCP client | — | DHCP client |
| IGMP snooping | Yes | Yes | Yes | — | — |
| IP-MAC-Port binding | Yes | — | — | Yes | Yes |
| Loop protection | Yes | Yes | Yes | Yes | Yes |
| MAC address filtering | — | Yes | Yes | — | — |
| Queue scheduling algorithms | Strict Priority Queue (SPQ), Weighted Round Robin (WRR) | — | — | Weighted Round Robin (WRR) | — |
| Security algorithms | 802.1x RADIUS, PEAP, SNMP, SNMPv2, SNMPv3, SSH, SSL/TLS, TTLS | — | — | EAP, LEAP, PEAP, SSH, TTLS | 802.1x RADIUS, SNMP, SSH |
| SSH/SSL support | Yes | — | — | — | Yes |
| Management features | |||||
| ARP inspection | Yes | Yes | Yes | — | — |
| Cloud-managed | — | — | — | No | — |
| Configuring Location Settings (CLI) | Yes | Yes | Yes | Yes | — |
| MIB support | SNMP MIB | Y | Y | RFC2893, RFC4213, RFC4291, RFC2464, RFC2462, RFC4862, RFC2461, RFC4861, RFC2573, RFC1321, RFC2284, RFC2865, RFC2716, RFC3580, RFC826, RFC2463, RFC4443, RFC792, RFC793, RFC768, RFC791, RFC2389, RFC4113, RFC4022, RFC2618, RFC2674, RFC1398, RFC1643, RFC1650, RFC2358, RFC2665, RFC2021, RFC271, RFC1757, RFC2819, RFC1442, RFC1901, RFC1902, RFC1903, RFC1904, RFC1905, RFC1906, RFC1907, RFC1908, RFC2578, RFC3418, RFC2573, RFC2575, RFC2576, RFC1212, RFC1213, RFC1215, RFC1493, RFC1157, RFC2620, | RFC1213MIB II, RFC1493, RFC1907, RFC1757, 2819, RFC2021, RFC1398, 1643, 1650, 2358, 2665, RFC2674, 4363, RFC 2233, 2863, RFC 2618, RFC 2620, RFC 2925 |
| Quality of Service (QoS) support | Yes | Yes | Yes | Yes | — |
| Switch layer | L2+ | L2 | L2 | L3 | — |
| Switch type | Managed | Managed | Managed | Managed | Managed |
| System event log | — | Yes | Yes | Yes | Yes |
| Web-based management | Yes | Yes | Yes | Yes | — |
| Ports & interfaces | |||||
| Basic switching RJ-45 Ethernet ports quantity | 8 | 48 | 24 | 48 | 24 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) | Gigabit Ethernet (10/100/1000) | Gigabit Ethernet (10/100/1000) | — | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity | — | 4 | 4 | — | — |
| Console port | RJ-45 | — | — | RJ-45 | RJ-45 |
| Fiber optic connector | — | — | — | — | SFP |
| Installed SFP modules quantity | — | 0 | 0 | 0 | 0 |
| Installed SFP+ modules quantity | — | 0 | 0 | 0 | — |
| Power connector | — | AC-in jack | AC-in jack | — | — |
| SFP module slots quantity | — | — | — | — | 4 |
| SFP+ module slots quantity | 2 | — | — | 4 | — |
| Performance | |||||
| Built-in processor | — | — | — | — | Yes |
| Fanless | No | — | — | — | — |
| Flash memory | — | 32 MB | 32 MB | — | 32 MB |
| Internal memory | — | 256 MB | 256 MB | 2048 MB | 128 MB |
| Mean time between failures (MTBF) | — | 236667 h | 469262 h | 309053.1 h | 294101 h |
| Memory type | — | DDR3-SDRAM | DDR3-SDRAM | DDR3-SDRAM | DDR3-SDRAM |
| Noise level | 61.4 dB | 52.4 dB | 51.7 dB | 51.2 dB | 52.4 dB |
| Certificates | |||||
| Certification | — | — | — | — | IEC61000-4-5, RoHS |
| Compliance certificates | BSMI, CE, Federal Communications Commission (FCC), RCM, VCCI | — | — | — | — |
| Weight & dimensions | |||||
| Depth | 250 mm | 430 mm | 140 mm | 430 mm | 210 mm |
| Height | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Weight | 3.7 kg | 6.26 kg | 2.15 kg | 3.85 kg | — |
| Width | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Design | |||||
| Electromagnetic compatibility | — | — | — | CE A, VCCI A, FCC A, IC, BSMI | FCC A, CE A, VCCI, C-Tick, BSMI, CCC |
| Form factor | — | 1U | 1U | — | 1U |
| Housing material | Metal | — | — | — | — |
| LED indicators | Yes | Yes | Yes | Activity, Link, Power, Speed | Activity, Fan fail, Link, Power, Speed |
| Number of fans | 2 fan(s) | — | 2 fan(s) | — | 2 fan(s) |
| Product colour | Black | Black | Black | Black | — |
| Rack mounting | Yes | Yes | Yes | — | Yes |
| Redundant fans support | Yes | — | — | — | — |
| Stackable | No | Yes | Yes | — | — |
| Optical fiber | |||||
| Fiber ethernet cabling technology | — | — | — | — | 1000BASE-X |
| Data transmission | |||||
| Forwarding rate | 148.8 Mpps | 77.4 Mpps | 41.7 Mpps | 130.95 Mpps | 41.7 Mpps |
| Jumbo frames | 10000 | 10000 | 10000 | 12000 | — |
| Jumbo frames support | Yes | Yes | Yes | — | — |
| MAC address table | 32000 entries | 16000 entries | 8000 entries | 32000 entries | 16000 entries |
| Number of IP interfaces | 16 | — | — | — | — |
| Number of queues | — | — | — | — | 8 |
| Number of static routes | — | — | — | 124 | — |
| Packet buffer memory | — | 12 MB | 4.1 MB | 16 MB | 1.5 MB |
| Store-and-forward | Yes | Yes | Yes | — | — |
| Switching capacity | 200 Gbit/s | 104 Gbit/s | 56 Gbit/s | 176 Gbit/s | 56 Gbit/s |
| Protocols | |||||
| GARP VLAN Registration Protocol (GVRP) | Yes | — | — | — | — |
| IPv4 & IPv6 features | ICMPv6 | — | — | — | — |
| Logistics data | |||||
| Harmonized System (HS) code | — | — | — | 85176990 | — |
| Operational conditions | |||||
| Heat dissipation | — | 1634.01 BTU/h | 900.36 BTU/h | 1512.676 BTU/h | 850.58 BTU/h |
| Operating relative humidity (H-H) | 0 - 95% | 0 - 95% | 0 - 95% | 0 - 95% | 10 - 90% |
| Operating temperature (T-T) | -5 - 50 °C | -5 - 50 °C | -5 - 50 °C | -5 - 50 °C | -5 - 50 °C |
| Storage relative humidity (H-H) | 0 - 95% | 0 - 95% | 0 - 95% | 0 - 95% | 5 - 90% |
| Storage temperature (T-T) | -40 - 70 °C | -40 - 70 °C | -40 - 70 °C | -20 - 70 °C | -40 - 70 °C |
| Packaging content | |||||
| Manual | Yes | — | — | — | — |
| Technical details | |||||
| Master (outer) cases per pallet (air) | — | — | — | 16 pc(s) | 24 pc(s) |
| Master (outer) cases per pallet (sea) | — | — | — | 16 pc(s) | 40 pc(s) |
| Pallet gross length | — | — | — | 110 cm | 110 cm |
| Pallet gross weight (air) | — | — | — | 456.1 kg | 419.7 kg |
| Pallet gross weight (sea) | — | — | — | — | 682.9 kg |
| Pallet gross width | — | — | — | 120 cm | 120 cm |
| Pallet height (air) | — | — | — | 184.7 cm | 131.4 cm |
| Pallet height (sea) | — | — | — | 184.7 cm | 2.1 m |
| Products per pallet (air) | — | — | — | 80 pc(s) | 72 pc(s) |
| Products per pallet (sea) | — | — | — | 80 pc(s) | 120 pc(s) |
| Products per shipping (inner) case | — | — | — | 5 pc(s) | 3 pc(s) |
| Shipping (inner) case gross weight | — | — | — | 27.4 kg | 16.4 kg |
| Shipping (inner) case height | — | — | — | 42.8 cm | 39.3 cm |
| Shipping (inner) case length | — | — | — | 58.5 cm | 53.9 cm |
| Shipping (inner) case net weight | — | — | — | 22.9 kg | 15.6 kg |
| Shipping (inner) case width | — | — | — | 47.8 cm | 29.5 cm |
| Multicast features | |||||
| Multicast Listener Discovery (MLD) snooping | — | — | — | — | MLD v1, MLD v2 |
| Multicast support | Yes | Yes | Yes | Yes | Yes |
| Packaging data | |||||
| Package depth | — | — | — | 563 mm | 521 mm |
| Package height | — | — | — | 89 mm | 92 mm |
| Package weight | — | — | — | 5.17 kg | 5.18 kg |
| Package width | — | — | — | — | 365 mm |
| Power over Ethernet (PoE) | |||||
| Power over Ethernet (PoE) | Yes | No | Yes | Yes | Yes |
| Power over Ethernet (PoE) ports quantity | — | — | 24 | 48 | 24 |
| Power over Ethernet (PoE) power per port | — | — | — | 15.4 W | — |
| Power over Ethernet (PoE) type supported | PoE++ (4PPoE) | — | — | — | — |
| Power over Ethernet 4PPoE (PoE++) ports quantity | 8 | — | — | — | — |
| Total Power over Ethernet (PoE) budget | 370 W | — | 193 W | 370 W | — |
