Eaton 9SX 9SX1500IRBS - UPS (rack-mountable)
Thumbnail 0
Thumbnail 1
Thumbnail 2
Thumbnail 3

Eaton 9SX 9SX1500IRBS - UPS (rack-mountable)

Manuf P/N: 9SX1500IRBS
APAXON#: 7221580
EAN: 3553340620454
Eaton 9SX 9SX1500IRBS - UPS (rack-mountable)
UPS (rack-mountable)
AC 200/208/220/230/240 V
1350 Watt
1500 VA
1-phase
9 Ah
RS-232, USB
output connectors: 6
PFC
2U
19"
black
Weight: 24.08 KG
  • True online double-conversion technology with high power density, utility frequency independence, and generator compatibility
  • ABM technology that uses advanced battery management to increase battery service life, optimize recharge time, and provide a warning before the end of useful battery life
  • Selectable high efficiency mode of operation
  • Firmware that is easily upgradable without a service call
  • Remote on/off control through Remote On/Off (ROO) and Remote Power Off (RPO) ports
UK Stock9
ConditionNew
Price £ 1,185.28
Price inc. VAT
£ 1,422.34
Quantity
|

Sales & Technical Enquiries

Product Summary

The Eaton 9SX uninterruptible power system (UPS) protects your sensitive electronic equipment from the most common power problems, including power failures, power sags, power surges, brownouts, line noise, high voltage spikes, frequency variations, switching transients, and harmonic distortion. Power outages can occur when you least expect it and power quality can be erratic. These power problems have the potential to corrupt critical data, destroy unsaved work sessions, and damage hardware - causing hours of lost productivity and expensive repairs.

Extended Specification

Power Device
Input Wiring
1-phase
Input Connectors
1 x power IEC 60320 C14
Power Output Connectors Details
6 x power IEC 60320 C13
Output Voltage
AC 200/208/220/230/240 V + 2% / - 2% - 50/60 Hz
Efficiency
91.4%, 97.4% Eco mode
Frequency Provided
50/60 Hz
Input Voltage
AC 200/208/220/230/240 V
Output Waveform
Sinewave
UPS Technology
On-line
Frequency Required
40 - 70 Hz
Power Factor (PF)
0.9
Power Capacity
1350 Watt / 1500 VA
Input Voltage Range
AC 120 - 276 V
Weight & Dimensions
Height
24 cm
Weight
18.8 kg
Depth
57 cm
Width
54.8 cm
General
Colour
Black
Rack Size
19"
Height (Rack Units)
2U
Device Type
UPS - Power Factor Correction (PFC) - rack-mountable
Connections & Expansion
Expansion Slots
1 (total) / 1 (free) x Expansion Slot
Interfaces
1 x management (RS-232) - 9 pin D-Sub (DB-9), 1 x management (USB) - 4 pin USB Type B, EPO (emergency power off) - mini terminal block, Relay output - mini terminal block
Manufacturer Warranty
Service & Support
Limited warranty - 2 years
Network
Remote Management Interface
RS-232, USB
Miscellaneous
Rack Mounting Kit
Included
Compliant Standards
TUV, CISPR 22 Class B, UL 1778, IEC 62040-2, cULus, CSA 22.2, EN 62040-2, EAC, IEC 62040-1, EN 62040-1, FCC Part 15 Class B
Cables Included
2 x power cable (IEC) - external, Serial cable - external, USB cable - external
Included Accessories
BS input cord
Features
Advance Battery Management (ABM), LCD display, internal bypass, deep discharge protection, automatic shut down, automatic self-test, hot-swappable batteries, temperature-compensated battery charging, double conversion
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Sound Emission
43 dB
Humidity Range Operating
0 - 95% (non-condensing)
Battery
Quantity
4
Technology
Lead Acid
Voltage Provided
12 V
Capacity
9 Ah
Run Time (Up To)
5.5 min at full load
Features
Sealed
Type
Expandable
Eaton 9SX 9SX1500IRBS - UPS (rack-mountable)

Disclaimers

  • Actual configuration might differ from illustration
