- Form Factor
- Desktop
- Line Coding Format
- OFDM, DSSS
- Connectivity Technology
- Wireless, wired
- Network / Transport Protocol
- TCP/IP, PPTP, UDP/IP, L2TP, ICMP/IP, IPSec, PPPoE, DHCP
- Frequency Band
- 2.4 GHz, 5 GHz
- Remote Management Protocol
- SNMP 2, SNMP 3, HTTP, HTTPS, SSH, CLI
- Routing Protocol
- OSPF, RIP-1, RIP-2, BGP, static IP routing, policy-based routing (PBR)
- Encryption Algorithm
- DES, Triple DES, MD5, SHA-1, PEAP, TTLS, TKIP, WPA, WPA2, 128-bit AES, 192-bit AES, 256-bit AES, WEP
- Authentication Method
- RADIUS, LDAP, XAUTH authentication
- Compliant Standards
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11e, IEEE 802.11n, IEEE 802.11k, IEEE 802.11ac, IEEE 802.11w, IEEE 802.11r, IEEE 802.11s
- Status Indicators
- Power, test mode, wireless, link/activity, SSD activity, secure
- Performance
- Firewall throughput: 3 Gbps, Threat prevention throughput: 1 Gbps, Application throughput: 1.5 Gbps, IPS throughput: 1.5 Gbps, Anti-malware throughput: 1 Gbps, TLS/SSL inspection and decryption throughput: 500 Mbps, VPN throughput (IPSec): 1.3 Gbps, Connection rate: 9000 connections per second
- Capacity
- Virtual interfaces (VLANs): 128, SSL VPN licences: 2 (maximum 100), VPN tunnels (site-to-site): 100, IPSec VPN clients: 5 (maximum 200), SPI connections: 900000, DPI connections: 200000, DPI SSL connections: 30000, Single Sign-On (SSO) users: 1000, Manageable access points: 16
- Data Link Protocol
- Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2
- Features
- Firewall protection, NAT support, VPN support, PAT support, VLAN support, Stateful Packet Inspection (SPI), DoS attack prevention, content filtering, port mirroring, IPv6 support, antivirus analysis, Deep Packet Inspection (DPI), DDos attack prevention, Wireless Intrusion Detection System (WIDS), Wi-Fi Multimedia (WMM) support, anti-spam protection, Quality of Service (QoS), Dead Peer Detection (DPD), IPSec NAT-Traversal (NAT-T), Jumbo Frames support, DHCP server, bandwidth control, IPv4 support, Common Access Card (CAC) reader support, DHCP relay, 3G/4G USB Dongle Support, NetFlow, rogue access point detection, dual-stream (2x2), Wireless Intrusion Prevention System (WIPS), Captive Portal, Single Sign-On (SSO) support, Bluetooth Low Energy Beaconing, beamforming technology, band steering, Fast Roaming, Airtime Fairness, VLAN trunking, SD-WAN support
