StarTech.com 1m DisplayPort 2.1 Cable, VESA-Certified, DP40 DP 2.1 Cable - DisplayPort cable - DisplayPort (M) latched to DisplayPort (M) latched - DisplayPort 2.1 - 1 m - UHBR10, HDR support, 8K60Hz support, 4K144Hz support, 1440p support 240Hz, up to 40 Gbps data transfer rate, passive - black
Manuf P/N: DP21-1M-DP40-CABLE
APAXON#: 10379313
EAN: 0065030909983
StarTech.com 1m DisplayPort 2.1 Cable, VESA-Certified, DP40 DP 2.1 Cable - DisplayPort cable - DisplayPort (M) latched to DisplayPort (M) latched - DisplayPort 2.1 - 1 m - UHBR10, HDR support, 8K60Hz support, 4K144Hz support, 1440p support 240Hz, up to 40 Gbps data transfer rate, passive - black
- 1 m
- DisplayPort Straight Male
- DisplayPort version: 2.1
- 7680 x 4320 pixels 144 Hz 40 Gbit/s
- HDCP Display Stream Compression (DSC)
- Black
Stock25
Price £11.18
Quantity
|
Similar Products
Product Summary
StarTech.com 1m DisplayPort 2.1 Cable, VESA Certified DP40 DisplayPort Cable w/UHBR10/HDR/HDCP 2.2, 8K 60Hz/4K 144Hz w/DSC 1.2a, 40Gbps, DP 2.1 Cable, UHD Monitor Cord, M/M
Extended Specification
Features
Cable length
1 m
Connector 1
DisplayPort
Connector 2
DisplayPort
Connector 1 gender
Male
Connector 2 gender
Male
Maximum resolution
7680 x 4320 pixels
Product colour
Black
Connector 1 form factor
Straight
Connector 2 form factor
Straight
Connector contacts plating
Nickel
DisplayPort version
2.1
Supported graphics resolutions
3840 x 2160, 7680 x 4320
Maximum refresh rate
144 Hz
HDCP
Yes
HDCP version
2.2
Display Stream Compression (DSC)
Yes
Display Stream Compression (DSC) version
1.2a
Latching connectors
Yes
Cable material
Copper
Cable shielding
Aluminum mylar foil
Jacket material
Thermoplastic elastomer (TPE)
AWG wire size
30
High Dynamic Range (HDR) supported
Yes
Data transfer rate
40 Gbit/s
Channels quantity
32 channels
Multi-Stream Transport (MST)
Yes
Fire-resistance rating
VW-1
Cable type
Round cable
Operational conditions
Operating temperature (T-T)
0 - 45 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
10 - 85%
Certificates
Compliance certificates
RoHS
Sustainability
Doesn't contain
Halogen
Sustainability compliance
Yes
Weight & Dimensions
Cable diameter
6.5 mm
Weight
66 g
Packaging data
Package width
128 mm
Package depth
220 mm
Package height
21 mm
Package weight
70 g
Packaging content
Quantity per pack
1 pc(s)
Logistics data
Master (outer) case width
500 mm
Master (outer) case length
320 mm
Master (outer) case height
210 mm
Products per master (outer) case
80 pc(s)
