TP-Link TL-SG1005LP - V1 - switch - unmanaged - 5 x 10/100/1000 (4 PoE+) - desktop, wall-mountable - PoE+ (40 W)
Thumbnail 0

TP-Link TL-SG1005LP - V1 - switch - unmanaged - 5 x 10/100/1000 (4 PoE+) - desktop, wall-mountable - PoE+ (40 W)

Manuf P/N: TL-SG1005LP
APAXON#: 5808061
EAN: 6935364052737
TP-Link TL-SG1005LP - V1 - switch - unmanaged - 5 x 10/100/1000 (4 PoE+) - desktop, wall-mountable - PoE+ (40 W)
  • Unmanaged
  • Quality of Service (QoS) support
  • Basic switching RJ-45 Ethernet ports quantity: 5
  • Cat3, Cat4, Cat5, Cat5e, Cat6 10BASE-T, 100BASE-TX, 1000BASE-T
  • MAC address table: 2000 entries Switching capacity: 10 Gbit/s
  • DC/PoE Power supply included Power over Ethernet (PoE)
UK Stock86
ConditionNew
Price £ 34.55
Price inc. VAT
£ 41.46
Quantity
|

Sales & Technical Enquiries

Product Summary

TP-Link TL-SG1005LP network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Extended Specification

Management features
Switch type
Unmanaged
Quality of Service (QoS) support
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
5
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity
0
Installed SFP+ modules quantity
0
Gigabit Ethernet (copper) ports quantity
5
Network
Networking standards
IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
10G support
No
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported
Cat3, Cat4, Cat5, Cat5e, Cat6
Flow control support
Yes
Auto MDI/MDI-X
Yes
Auto-negotiation
Yes
MAC address auto-learning supported
Yes
MAC address auto-aging supported
Yes
Data transmission
MAC address table
2000 entries
Switching capacity
10 Gbit/s
Forwarding rate
7.44 Mpps
Store-and-forward
Yes
Jumbo frames support
Yes
Jumbo frames
16000
Security
IGMP snooping
Yes
Design
Rack mounting
No
Stackable
No
Product colour
Black
LED indicators
Yes
Wall mountable
Yes
Performance
Maximum cable length
100 m
Fanless
Yes
Power
Power source
DC/PoE
Power supply included
Yes
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
DC input voltage
53.5 V
Input current
0.81 A
Power consumption (max)
47.5 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet plus (PoE+) ports quantity
4
Total Power over Ethernet (PoE) budget
40 W
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
5 - 90%
Heat dissipation
161.98 BTU/h
Weight & dimensions
Width
99.8 mm
Depth
98 mm
Height
25 mm
Packaging content
User guide
Yes
Packaging data
Package type
Box
Package width
131 mm
Package depth
196 mm
Package height
121 mm
Package weight
730 g
Certificates
Compliance certificates
CE, Federal Communications Commission (FCC), RoHS
Certification
FCC, CE, RoHS
Logistics data
Harmonized System (HS) code
85176990
Sustainability
Sustainability compliance
Yes
