D-Link Web Smart DGS-1210-10P
Manuf P/N: DGS-1210-10P
APAXON#: 1966019
EAN: 0790069329432
D-Link 10-port 10/100/1000 Gigabit PoE Smart Switch including 2 Combo 1000BaseT/SFP
Weight: 3.08 KG
Weight: 3.08 KG
- Managed L2 Web-based management
- Quality of Service (QoS) support
- Basic switching RJ-45 Ethernet ports quantity: 8
- Cat5, Cat5e 10BASE-T, 100BASE-T, 1000BASE-T
- MAC address table: 8000 entries Switching capacity: 20 Gbit/s
- Static Routing and MSTP
- PoE options up to 370W power budget
- Dual image & config
UK Stock0
ConditionNew
Price £ 102.76
Price inc. VAT
£ 123.31
Quantity
|
Sales & Technical Enquiries
Phone: 0161 464 9941Email: sales@apaxon.co.uk
Similar Products
Product Summary
The DGS-1210-10/10P/20/28 features a fanless design that allows for quieter operation and helps to extend the device's lifetime. While the DGS-1210-28P/52/52P feature a smart fan design that powers on after the switch reaches a certain temperature, saving energy and cutting costs without sacrificing performance.
Extended Specification
Data transmission
Packet buffer memory
0.512 MB MB
MAC address table
8000 entries entries
Switching capacity
20 Gbit/s Gbit/s
Forwarding rate
14.88 Mpps Mpps
MAC address table
8000 entries
Switching capacity
20 Gbit/s
Forwarding rate
14.88 Mpps
Store-and-forward
Yes
Packet buffer memory
0.512 MB
Technical details
Products per pallet (air)
180 pc(s) pc(s)
Pallet gross length
110 cm cm
Pallet gross width
120 cm cm
Pallet height (air)
140.3 cm cm
Pallet gross weight (sea)
662 kg kg
Master (outer) cases per pallet (sea)
54 pc(s) pc(s)
Products per pallet (sea)
270 pc(s) pc(s)
Pallet height (sea)
2.04 m m
Shipping (inner) case gross weight
11.8 kg kg
Shipping (inner) case height
31.7 cm cm
Shipping (inner) case width
34.6 cm cm
Shipping (inner) case length
38.2 cm cm
Shipping (inner) case net weight
11.1 kg kg
Products per shipping (inner) case
5 pc(s) pc(s)
Pallet gross weight (air)
449.5 kg kg
Master (outer) cases per pallet (air)
36 pc(s) pc(s)
Shipping (inner) case height
31.7 cm
Shipping (inner) case width
34.6 cm
Shipping (inner) case length
38.2 cm
Shipping (inner) case net weight
11.1 kg
Products per shipping (inner) case
5 pc(s)
Pallet gross weight (air)
449.5 kg
Master (outer) cases per pallet (air)
36 pc(s)
Products per pallet (air)
180 pc(s)
Pallet gross length
110 cm
Pallet gross width
120 cm
Pallet height (air)
140.3 cm
Pallet gross weight (sea)
662 kg
Master (outer) cases per pallet (sea)
54 pc(s)
Products per pallet (sea)
270 pc(s)
Pallet height (sea)
2.04 m
Shipping (inner) case gross weight
11.8 kg
Performance
Noise level
0 dB dB
Mean time between failures (MTBF)
729258 h h
Noise level
0 dB
Mean time between failures (MTBF)
729258 h
Power
Power consumption (max)
80.6 W W
Power consumption (max)
80.6 W
Voltage Required
AC 120/230 V (50/60 Hz)
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget
78 W W
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) ports quantity
8
Power over Ethernet plus (PoE+) ports quantity
2
Total Power over Ethernet (PoE) budget
78 W
Operational conditions
Operating temperature (T-T)
-5 - 50 °C °C
Storage temperature (T-T)
-20 - 70 °C °C
Operating relative humidity (H-H)
0 - 95% %
Storage relative humidity (H-H)
0 - 95% %
Heat dissipation
373.96 BTU/h BTU/h
Operating temperature (T-T)
-5 - 50 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Heat dissipation
373.96 BTU/h
Weight & dimensions
Width
280 mm mm
Depth
126 mm mm
Height
44 mm mm
Weight
950 g g
Width
280 mm
Depth
126 mm
Height
44 mm
Weight
950 g
Packaging data
Package width
288 mm mm
Package depth
331 mm mm
Package height
72 mm mm
Package weight
2.21 kg kg
Package width
288 mm
Package depth
331 mm
Package height
72 mm
Package weight
2.21 kg
Management features
Switch type
Managed
Switch layer
L2
Quality of Service (QoS) support
Yes
Web-based management
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity
0
Installed SFP+ modules quantity
0
Gigabit Ethernet (copper) ports quantity
8
SFP module slots quantity
2
Power connector
DC-in jack
Network
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
10G support
No
Copper ethernet cabling technology
10BASE-T, 100BASE-T, 1000BASE-T
Cable types supported
Cat5, Cat5e
Port mirroring
Yes
Full duplex
Yes
Flow control support
Yes
Link aggregation
Yes
Auto MDI/MDI-X
Yes
Security
Access Control List (ACL)
Yes
MAC address filtering
Yes
Multicast features
Multicast support
Yes
Design
Rack mounting
Yes
Stackable
Yes
Form factor
1U
Product colour
Black
LED indicators
Yes
Certificates
Certification
EMI: CE Class A, VCCI Class A, FCC Class A, BSMI, CCC
Logistics data
Harmonized System (HS) code
85176990
General
Built-in Devices
Led panel
Subtype
Gigabit Ethernet
Authentication Method
RADIUS
Remote Management Protocol
SNMP 1, SNMP 2, Telnet, HTTP, TFTP
Device Type
Switch - 10 ports - Managed
Ports
8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP
Enclosure Type
Desktop 1U
Status Indicators
Port transmission speed, power, link OK, link/activity
Features
Flow control, full duplex capability, Layer 2 switching, DHCP support, auto-negotiation, BOOTP support, RARP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, WRR queuing, store and forward, MAC address filtering, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, STP support, ACL support, QoS, DHCP server, Safeguard Engine
Disclaimers
- Product data is provided by CNET, we do not warrant the accuracy and completeness of the material contained in this data sheet
