Eaton 5S 550i
UPS
AC 220/230/240 V
330 Watt
550 VA
1-phase
5 Ah
USB
output connectors: 4
black
Weight: 5.98 KG
- Power management: enhance your power protection capabilities and ensure safe system shutdown
- LCD display: access critical UPS information including battery time and outage tracking in a single screen view with the user friendly LCD
- Eco-control: save up to 30 percent on energy consumption by shutting down non-essential peripherals when the computer is turned off
- Convenient form factor: fit the 5S easily into tight spaces with its slim form factor
- Surge protection: provide surge protection for network phone lines, cable TV and satellite applications
Similar Products
Overview
The compact Eaton 5S UPS delivers backup power for desktop PCs and workstations. The eco-control capability enables you save up to 30 percent in energy consumption. The 5S displays critical UPS information on battery time and outage tracking through a user-friendly LCD interface.
Specifications
Environmental Parameters
- Humidity Range Operating
- 0 - 85%
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 35 °C
Battery
- Quantity
- 1
- Technology
- Lead Acid
- Voltage Provided
- 12 V
- Capacity
- 5 Ah
- Features
- Sealed
- Run Time (Up To)
- 1 min at full load, 10 min at half load, 6 min at 70% load
Power Device
- Input Voltage
- AC 220/230/240 V
- UPS Technology
- Line interactive
- Power Factor (PF)
- 0.6
- Efficiency
- 97%
- Circuit Protection
- Circuit breaker
- Frequency Required
- 46 - 70 Hz
- Power Capacity
- 330 Watt / 550 VA
- Input Voltage Range
- AC 175 - 275 V
- Dataline Surge Protection
- Network/phone line - RJ-45/RJ-11 - 1 input line / 1 output line
- Input Wiring
- 1-phase
- Input Connectors
- 1 x power IEC 60320 C14
- Output Voltage
- AC 184-276 V
- Power Output Connectors Details
- 3 x power IEC 60320 C13 (surge), 1 x power IEC 60320 C13 (UPS and surge)
Weight & dimensions
- Depth
- 26 cm
- Height
- 25 cm
- Width
- 8.7 cm
- Weight
- 5.9 kg
General
- Colour
- Black
- Device Type
- UPS - external
Connections & Expansion
- Interfaces
- 1 x management (USB) - 4 pin USB Type B
Manufacturer Warranty
- Service & Support
- Limited warranty - 2 years, Limited warranty - batteries - 2 years
Network
- Remote Management Interface
- USB
Miscellaneous
- Features
- Automatic Voltage Regulation (AVR), deep discharge protection, cold-start function, booster technology, fader technology
- Compliant Standards
- CB, IEC 62040-1, EN 62040-1, IEC/EN 62040-4
- Included Accessories
- BS cord 10A
- Cables Included
- USB cable, 2 x power cable (IEC)
