TP-Link TL-SG105PP-M2 V1.6 - Switch - unmanaged - 5 x 10/100/1000/2.5G (PoE++) - desktop - PoE++ (123 W)
Manuf P/N: TL-SG105PP-M2
APAXON#: 8658243
EAN: 4895252501148
TP-Link TL-SG105PP-M2 V1.6 - Switch - unmanaged - 5 x 10/100/1000/2.5G (PoE++) - desktop - PoE++ (123 W)
- Unmanaged
- Quality of Service (QoS) support
- Basic switching RJ-45 Ethernet ports quantity: 5
- Cat3, Cat4, Cat5, Cat5e 10BASE-T, 100BASE-TX, 1000BASE-T
- MAC address table: 4000 entries Switching capacity: 25 Gbit/s
- DC/PoE Power supply included Power over Ethernet (PoE)
Stock4
Price £0.00
Quantity
|
Similar Products
TP-Link TL-SG105PP-M2 V1.6 - Switch - unmanaged - 5 x 10/100/1000/2.5G (PoE++) - desktop - PoE++ (123 W)
Your Choice
—
—
—
—
Stock4
£0.00
TP-Link JetStream TL-SG2008P - V1 - switch - smart - 4 x 10/100/1000 + 4 x 10/100/1000 (PoE+) - desktop - PoE+ (62 W)
Better
—
—
—
—
Stock2
£0.00
Product Summary
TP-Link 5-Port 2.5G Desktop Switch with 4-Port PoE++
Extended Specification
Group 2944
Switch type
Unmanaged
Quality of Service (QoS) support
Yes
Group 763
Basic switching RJ-45 Ethernet ports quantity
5
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity
0
Installed SFP+ modules quantity
0
2.5G Ethernet (copper) ports quantity
5
Group 1141
Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
10G support
No
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported
Cat3, Cat4, Cat5, Cat5e
Flow control support
Yes
Auto MDI/MDI-X
Yes
Auto-negotiation
Yes
MAC address auto-learning supported
Yes
MAC address auto-aging supported
Yes
Group 2484
MAC address table
4000 entries
Switching capacity
25 Gbit/s
Forwarding rate
18.6 Mpps
Store-and-forward
Yes
Group 2482
IGMP snooping
Yes
Group 10881
Rack mounting
No
Product colour
Black
Housing material
Steel
LED indicators
Yes
Group 10882
Fanless
Yes
Group 1142
Power source
DC/PoE
Power supply included
Yes
Number of power supply units
1
AC input voltage
220 V
AC input frequency
50 Hz
Input current
2.43 A
Input voltage
53.5 V
Power consumption (max)
143.37 W
Group 9999
Power over Ethernet (PoE)
Yes
Power over Ethernet 4PPoE (PoE++) ports quantity
4
Power over Ethernet (PoE) power per port
60 W
Total Power over Ethernet (PoE) budget
123 W
Group 1143
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
5 - 90%
Heat dissipation
488.89 BTU/h
Group 1144
Width
209 mm
Depth
126 mm
Height
26 mm
Group 49104
Cables included
AC
User guide
Yes
Group 2483
Package type
Box
Group 41469
Certification
CE, FCC, RoHS
