Zyxel GS1900-24EP - Switch
Thumbnail 0
Thumbnail 1
Thumbnail 2
Thumbnail 3

Zyxel GS1900-24EP - Switch

Manuf P/N: GS1900-24EP-GB0101F
APAXON#: 8568290
EAN: 4718937609475
Zyxel GS1900-24EP
Switch
smart
24 x 10/100/1000 (12 PoE+)
rack-mountable, wall-mountable
PoE+ (130 W)
Weight: 3.48 KG
  • Near silent operation
  • Intelligent PoE+ powers more devices
  • Speedy Gigabit performance - built for SMBs
  • Easy and intuitive management
UK Stock4
ConditionNew
Price £ 211.09
Price inc. VAT
£ 253.31
Quantity
|

Sales & Technical Enquiries

Product Summary

The GS1900 series includes both fan-less and built-in smart fan models. The smart fan is designed to automatically adjust speed based on device temperature. You can barely hear the sound while the switch is operating. It is ideal for your office environment. It comes with default PoE consumption mode which delivers only the actual power required by your networked devices, reserves the rest, and optimizes its power budget. That means a single switch can power more APs, IP cameras, and VoIP phones, ensuring a better ROI for your business. All of them support the IEEE 802.3at providing a maximum of 30W per port. The GS1900 is a series of switches with full non-blocking bandwidth. An ideal upgrade from an unmanaged switch, it's a great choice for SMBs that want to enjoy high-speed business network applications at full wired non-blocking speed. The smart managed GS1900 series switch feature with a web-based interface to manage advanced functions such as VLAN, QoS, IGMP snooping, link aggregation, IPv6, and Dos prevention easily. Also, the user-friendly wizard helps to walk through setup, configuration, and even advanced settings quickly.

Extended Specification

Network
Flow control support
Yes
Link aggregation
Yes
Auto MDI/MDI-X
Yes
Spanning tree protocol
No
Ethernet LAN data rates
10,100,1000 Mbit/s
MAC address auto-learning supported
Yes
VLAN support
Yes
Virtual LAN features
Tagged VLAN, VLAN Identifier ( VLAN ID), Voice VLAN
Ethernet LAN data rates
10,100,1000 Mbit/s Mbit/s
Networking standards
IEEE 802.1D, IEEE 802.1ab, IEEE 802.1af, IEEE 802.1s, IEEE 802.1w, IEEE 802.3at, IEEE 802.3az, IEEE 802.3p, IEEE 802.3u, IEEE 802.3x
10G support
No
Cable types supported
Cat5, Cat5e
Port mirroring
Yes
Full duplex
Yes
Data transmission
MAC address table
8000 entries
Switching capacity
48 Gbit/s
Forwarding rate
35.7 Mpps
Store-and-forward
Yes
Jumbo frames support
Yes
Jumbo frames
9000
Packet buffer memory
0.525 MB
MAC address table
8000 entries entries
Switching capacity
48 Gbit/s Gbit/s
Forwarding rate
35.7 Mpps Mpps
Packet buffer memory
0.525 MB MB
Security
DHCP features
DHCP client
IGMP snooping
Yes
Security algorithms
802.1x RADIUS
MAC address filtering
Yes
Static port security
Yes
SSH/SSL support
Yes
Password protection
Yes
Authentication type
HWTACACS+, IEEE 802.1x, RADIUS
Multicast features
Multicast support
Yes
Design
Rack mounting
Yes
Stackable
Yes
Product colour
Black
Reset button
Yes
Performance
Noise level
26 dB
Noise level
26 dB dB
Power
Power source
AC
Power supply included
Yes
Voltage Required
AC 120/230 V (50/60 Hz)
AC input frequency
50/60 Hz
Power consumption (max)
166.5 W
AC input voltage
100 - 240 V V
AC input frequency
50/60 Hz Hz
Power consumption (max)
166.5 W W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) ports quantity
12
Total Power over Ethernet (PoE) budget
130 W
Total Power over Ethernet (PoE) budget
130 W W
Weight & dimensions
Width
330 mm
Depth
230 mm
Height
44 mm
Weight
2.48 kg
Width
330 mm mm
Depth
230 mm mm
Height
44 mm mm
Weight
2.48 kg kg
Packaging content
Cables included
AC
Quick start guide
Yes
User guide
Yes
Manual
Yes
General
Subtype
Gigabit Ethernet
Encryption Algorithm
SSL
Status Indicators
Status
Authentication Method
RADIUS, TACACS+
Enclosure Type
Rack-mountable, wall-mountable
Device Type
Switch - 24 ports - smart
Ports
24 x 10/100/1000 (12 PoE+)
Routing Protocol
IGMPv2, IGMP, IGMPv3, MSTP, RSTP, STP
Performance
Switching capacity: 48 Gbps Forwarding performance: 35.7 Mpps Packet buffer size: 525 KB
Remote Management Protocol
SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, NTP, ICMP, DHCP, IPv6, RSTP, TACACS+, RADIUS
Features
Flow control, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, DoS attack prevention, port mirroring, store and forward, MAC address filtering, IPv6 support, half duplex mode, full duplex mode, firmware upgradable, QoS, LACP support, LLDP support, Port Security, DHCP client, dual firmware images, SPQ, NDP, CoS, ToS, Storm Control, MIB II, schedule PoE, Voice VLAN, LLDP-MED, Guest VLAN, EEE, WRR, VLAN Tagging, priority mapping, LAG
Management features
Switch type
Managed
Switch layer
L2
Quality of Service (QoS) support
Yes
MIB support
RFC 1213 MIB II RFC 2819 RMON (group 1, 2, 3, 9) RFC 1215 generic traps RFC 1493 bridge Zyxel private common MIB
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
24
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity
0
Installed SFP+ modules quantity
0
Power connector
AC-in jack
Zyxel GS1900-24EP - Switch

Disclaimers

  • Product data is provided by CNET, we do not warrant the accuracy and completeness of the material contained in this data sheet
