D-Link DGS 108GL
Thumbnail 0
Thumbnail 1
Thumbnail 2
Thumbnail 3

D-Link DGS 108GL

Manuf P/N: DGS-108GL/B
APAXON#: 7274179
EAN: 790069458613
D-Link DGS 108GL
Switch
unmanaged
8 x 10/100/1000
desktop
Weight: 0.40 KG
  • Eight Gigabit Ethernet LAN ports ensure stable, high-speed connections
  • Integrated D-Link Green technology optimizes operation and reduces power waste
  • Hardy metal casing keeps equipment safe and better dissipates heat
  • Simple plug and play setup for easy network integrations
  • Fanless design lengthens product life and grants silent operation
UK Stock18
ConditionNew
Price £ 19.82
Price inc. VAT
£ 23.78
Quantity
|

Sales & Technical Enquiries

Product Summary

The DGS-108GL boasts peak value for home offices or SMBs in enabling easy and rapid network expansions, upgrading connections with a hassle-free plug and play switch solution.

Extended Specification

Network
Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G support
No
Flow control support
Yes
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
Auto MDI/MDI-X
Yes
Data transmission
MAC address table
4000 entries
Switching capacity
16 Gbit/s
Store-and-forward
Yes
Packet forwarding rate (1 Gbps)
1488000 pps
Packet forwarding rate (100 Mbps)
148800 pps
Packet forwarding rate (10 Mbps)
14880 pps
Forwarding rate
11.9 Mpps Mpps
Number of queues
8
Jumbo frames support
Yes
Jumbo frames
9216
Packet forwarding rate (1 Gbps)
1488000 pps pps
Packet forwarding rate (100 Mbps)
148800 pps pps
Packet forwarding rate (10 Mbps)
14880 pps pps
MAC address table
4000 entries entries
Switching capacity
16 Gbit/s Gbit/s
Design
Rack mounting
No
Stackable
No
Product colour
Black
LED indicators
Yes
Stackable
Yes
Form factor
Desktop
Housing material
Metal
LED indicators
Activity, Link, Power
Performance
Mean time between failures (MTBF)
1402428 h
Mean time between failures (MTBF)
1402428 h h
Power
Power source
AC
Power supply included
Yes
DC input voltage
5 V
Input current
1 A
Power consumption (max)
4.31 W
Power source
DC
DC input voltage
5 V V
Input current
1 A A
Power consumption (max)
4.31 W W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-10 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
5 - 95%
Heat dissipation
14.7 BTU/h
Operating temperature (T-T)
0 - 40 °C °C
Storage temperature (T-T)
-10 - 65 °C °C
Operating relative humidity (H-H)
10 - 90% %
Storage relative humidity (H-H)
5 - 95% %
Heat dissipation
14.7 BTU/h BTU/h
Management features
Switch type
Unmanaged
Quality of Service (QoS) support
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity
0
Installed SFP+ modules quantity
0
Weight & dimensions
Width
140 mm
Depth
67 mm
Height
26 mm
Weight
240 g
Width
140 mm mm
Depth
67 mm mm
Height
26 mm mm
Weight
240 g g
Certificates
Compliance certificates
CE, RoHS
Certification
CE; FCC; RoHS
Logistics data
Harmonized System (HS) code
85176990
General
Enclosure Type
Desktop
Subtype
Gigabit Ethernet
Ports
8 x 10/100/1000
Device Type
Switch - 8 ports - unmanaged
Status Indicators
Power, link/activity
Capacity
Queues: 8
Performance
Switching capacity: 16 Gbps, Packet filter/forwarding rate (10 Mbps): 14880 pps, Packet filter/forwarding rate (100 Mbps): 148800 pps, Packet filter/forwarding rate (1000 Mbps):: 1488000 pps, Forwarding rate: 11.9 Mpps
Features
Flow control, auto-uplink (auto MDI/MDI-X), store and forward, QoS, D-Link Green Technology, fanless, metal housing, VoIP support, NAS support, SOHO, EEE
D-Link DGS 108GL
